Lutron Electronics HomeWorks Protocol Manual page 43

SVS_MON
SVS Monitor
String
Syntax
SVS, <address>, <scene command>, <status>
Parameter Description
address system address of Sivoia control that
changed
scene Sivoia scene command
command
status current status of the scene command
Description
The SVS monitor string is output from a processor when a Sivoia changes scene commands.
Example 1
Someone selects Preset 1 on the Sivoia controlled by processor 1, link 6, Sivoia control
address 3.
SVS, [01:06:03], 1, MOVING
When the same Sivoia stops at Preset 1.
SVS, [01:06:03], 1, STOPPED
Example 2
Someone selects the raise command on the Sivoia controlled by processor 1, link 6, Sivoia
control address 3.
http://www.lutron.com/hwi/Help/l232/svs_mon.htm (1 of 2) [7/3/03 1:19:50 PM]
Sivoia Scene Command Monitor
Format
[processor : link : address]
see
description
1 = Preset 1
2 = Preset 2
3 = Preset 3
R = Raise
L = Lower
C = Close
o = Open
S = Stop
STOPPED or MOVING
Output String
device address formatting
