Device Address Formatting
Device Address Formatting
Every physical device in the system (RPM zone, D48 zone, GRAFIK Eye, etc) has a system device
address.
Each device address is separated into 3-5 elements as shown in the tables below
Device address elements are listed in the order shown, separated by a period, colon, slash, backslash
or dash.
The entire device address may be enclosed in [brackets] if desired.
All letters and spaces in the address are ignored and may be used to improve readability
Examples of device address formats for Processor 1, Link 1, Module Interface Address 3, RPM Module
2, RPM zone 4
[01:01:03:02:04]
1:1:3:2:4
1.1.3.2.4
1/1/3/2/4
[proc 1 : link 1 : mi 3 : module 2 : zone 4]
Processor
Processor
http://www.lutron.com/hwi/Help/l232/device_addressing.htm (1 of 3) [7/3/03 1:19:40 PM]
Link
1-16 1
Link
RPM Dimmer/Switch
Router (MI)
0-15
D48 Dimmer/Switch
Router (D48)
Module Output
1-8 1-4
Bus Dimmer
