Frontload Washer
Speed Queen
Quantum Platinum
Refer to Page 8 for Model Identification
TLW2238N_SVG
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 806526ENR2
August 2017
