SSV Works RZ3-3A Manual page 6

RUNNING AMP POWER CABLE AND REAR SPEAKER WIRE
A. Unwrap the tape and pull the rubber wire grommet out of the firewall.
C. From under the hood, against the top firewall, unscrew the nut on the first
position terminal (12v accessory) and attach the yellow POWER wire. Refasten
on the nut (C1). Then unscrew the nut on the second position terminal and
attach the black GROUND wire. Re-screw on the nut (C2).
D. Feed the connector end of the Amp power wire through the center console to the other side of the firewall (D1). Then feed the power wire through the
grommet hole (D2) and through the rubber grommet with the rest of the vehicle's wiring and cables (D3). Do the same for the rear speaker wire.
C1
D1
A
B. Pull the MRB3 POWER and GROUND wires through the rubber
grommet and feed through the hole in the firewall to the power strip
located on the opposite side of the firewall.
NOTE
Some RZR models come with the ground "GND" terminal not
C2
connected as shown. If you do not have a factory wiring going to
this terminal, add a ground wire from the "GND" terminal to the
frame before connecting the wires. We recommend removing
the paint to bare metal, using a star washer, and repainting over
the connection.
D2
B
D3
