SSV Works RZ3-3A Manual page 37

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. Labor for replacement of defective
components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- Wire Crimpers
- Wire Strippers
- 10mm Socket or Wrench
- 13mm Socket or Wrench
PARTS LIST IMAGES
1. WP-RZ3GBS10
Enclosure
(door not included)
6. "L" Bracket x 1
INSTALLATION NOTES
If the vehicle has SSV Works front kick panels (RZ3-FKP65) installed, the passenger side kick panel will need to be removed prior to
installation of the WP-RZ3GBS10. Removal of the passenger fender is not required (Step C); however it will make the installation and
alignment of the WP-RZ3GBS10 easier. The use of a thread locker is recommended on all screws to prevent loosening due to vibration.
- T-40 Torx Driver
- #3 Phillips Screwdriver
- Panel removal tool
2. M6 x 1.0 Screws x 11
(Long)
7. Glove Box Door 8. Fuseholder with fuse,
Bracket x 1
PARTS LIST
1. WP-RZ3GBS10 Enclosure
2. M6 x 1.0 Screws x 11
(Long)
3. M6 x 1.0 Screws x 2 (Short)
4. M6 Washers x 13
5. Flat Mounting Brackets x 2
3. M6 x 1.0 Screws x 2
(Short)
Heat Shrink, Ring terminal
(1 each)
WP-RZ3GBS10
RZR 1000 & RZR900 2015+
Powered Glove Box Subwoofer
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
6. "L" Bracket x 1
7. Glove Box Door bracket x 1
8. Fuseholder with fuse, Heat
Shrink, Ring terminal (1 each)
9. Audio extension cable (94")
10. Zip ties x 5
4. M6 Washers x 13
9. Audio extension
cable (94")
5. Flat Mounting
Brackets x 2
10. Zip ties x 5
