SSV Works RZ3-3A Manual page 10

A. Remove the ten T40 Torx bolts that secure the 2 piece fender.
Note: there is one screw inside the fender well. Remove the
two additional screws from the striker plate, slide fender up
the cage rail and secure
C. Lift the enclosure into place and align the top channel in the grab handle
bar, while holding the enclosure in place, loosely attached the fl at brackets
to the top of the enclosure using the long screws provided.
E. While applying pressure keeping the enclosure secure against
the front wall, tighten the top brackets, as they tighten they
will bend slightly to add pressure and avoid any vibration, now
tighten the lower L bracket to the enclosure
A
C
E
B. Remove the two 10mm bolts the secure factory glove box and
remove the factory glove box
C
D. To properly align the box, slide the box fi rmly toward the front of
the vehicle. It should sit approximately 1/4" from the factory
glove box mount. If not properly installed, the dash of the vehicle
will not securely push back into position.
F. Loosely install the bottom L bracket, align the mounting hole with
the factory bung and secure with one of the long screws provided
(you will tighten the bracket to the enclosure and factory bung
AFTER step H)
D
B
D
F
10
