SSV Works RZ3-3A Manual page 34

A. Remove the ten T40 Torx bolts that secure the 2 piece fender.
Note: there is one screw inside the fender well. Remove the
two additional screws from the striker plate, slide fender up
the cage rail and secure
NOTE: If pod does not come pre-installed with speaker, do not use provided paper templates. Use the pod mounting holes as your drill template.
Hold the pod in position and mark the drill holes through the empty pod using a scribe tool. All pilot holes will be drilled from the inside footwell.
C. Cut out the INSIDE template (Driver/Passenger) along the cut line. Position the template on the inside footwell making sure to
square up the template along the factory panel as shown in image C1 and C2. Using a scribing tool, mark the center of the 2 drill
points illustrated on the template as shown in C3 and C4.
RZ3-F65
A
B. Using the utility knife or another cutting tool cut off the two
plastic factory nubs in the foot well, cut these as smooth as
you can to the panel.
C1
C3
B
C2
C4
