SSV Works RZ3-3A Manual page 16

E1 E2
E. Drill a pilot hole at the places just marked with a 1/8" drill bit. Then follow up by using a 1/4" drill bit for both pilot holes (for mounting the pod).
F
F. Route the speaker cable attached to the pod through the inside footwell 1/2"
hole. Position the speaker pod in place and line up with drilled mounting holes
G G
G. With the provided M6 screws and washers, loosely mount the pod through the 3 holes previously drilled. Once all screws have been
insterted into the pod, hand tighten all 3 screws.
H I
H. Connect the B-H1149 cable to the speaker pods and zip tie all I. Connect the speaker harness to the amplifi er
cables to the frame
16
