DLm8500 System Service Area and Removal
Figure 10 Shipping dimensions
81.00 in.
(205.7 cm)
48.00 in.
42.00 in.
(121.9 cm)
(106.7 cm)
GEN-001140
Use a mechanical lift or pallet jack to position the packaged cabinet in its final location.
Leave approximately 96 in. of clearance at the back of the cabinet to unload the unit
and roll it off the pallet as illustrated in the following figure:
