Hardware Installation Guide
Dell EMC Integrated Data Protection Appliance
DP4400
Version 2.4
302-005-680
REV. 03
September 2019
overview.................................................................................................. 2
rails............................................................................................................5
bezel..........................................................................................................9
iDRAC...................................................................................................... 12
resources................................................................................................. 15
system.................................................................... 3
Tool...................................................................................5
cabinet................................................................................... 6
cabinet................................................................................. 7
network......................................................................... 10
on...................................................................11
Manager.......................................................... 15
patch.........................................12
Advertisement
Table of Contents
Related Manuals for Dell EMC DP4400
Summary of Contents for Dell EMC DP4400
-
Page 1: Table Of Contents
Hardware Installation Guide Dell EMC Integrated Data Protection Appliance DP4400 Version 2.4 302-005-680 REV. 03 September 2019 Installation overview....................2 Prepare the site and unpack the system..............3 Install Network Validation Tool...................5 Install the rails......................5 Secure the rails to the cabinet................... -
Page 2: Installation Overview
Hardware Installation Guide Installation overview This guide is designed for personnel who install, configure, and maintain the Integrated Data Protection Appliance DP4400. To use this hardware publication, you should be familiar with digital storage equipment and cabling. Before you begin... -
Page 3: Prepare The Site And Unpack The System
Note that all components must run on a single VLAN or subnet with the exception of the iDRAC interface, which can be on a separate subnet or VLAN. For further information about IP addresses, see Table 1 on page 5. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... - Page 4 Hardware Installation Guide Note: The DP4400 installation requires IP addresses strictly from a single subnet having a single gateway. 2. Register the 13 IP addresses in DNS with forward and reverse lookup entries for each address. Ensure that the router for the 13 IP addresses can be pinged.
-
Page 5: Install Network Validation Tool
2. Fully extend the rear sliding bracket of the rail. 3. Position the rail end piece labeled Left Front facing inward and orient the rear end piece to align with the holes on the rear cabinet flanges. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... -
Page 6: Secure The Rails To The Cabinet
About this task Note: For square hole cabinets, install the supplied conical washer before installing the screw. For unthreaded round hole cabinets, install only the screw without the conical washer. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... -
Page 7: Install The System In The Cabinet
Procedure 1. At front of the cabinet, pull the inner slide rails out of the cabinet until they lock into place. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... - Page 8 The slam latches will engage to secure the system in the cabinet. Note: Ensure that the inner rail slides completely into the middle rail. The middle rail locks if the inner rail is not fully engaged. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide...
-
Page 9: Install The Bezel
1. Align and insert the right end of the bezel onto the system. 2. Press the release button and fit the left end of the bezel onto the system. 3. Lock the bezel by using the key. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... -
Page 10: Connect The System To The Network
2. If the DP4400 contains 10Gb BASE-T network cards, use Cat6a UTP or Cat7 copper cables to connect to the network switch. 3. If the DP4400 contains 10GB SFP network cards, use fiber cables with a 10 Gb optical SFP, 1GBaseT RJ-45 SFP with Cat5e or Cat6 UTP copper Ethernet cables, or direct-attached copper cables to connect the four required 10 GbE ports (2, 3, 8, 9) to access ports on the switch in your network. -
Page 11: Connect The Power Cables And Power On
DP4400 ports About this task The following table provides the callout number and the type of port for the DP4400 ports in Figure 1 DP4400 network and iDRAC connections . Table 2 DP4400 port types... -
Page 12: Configure Idrac
N.N.N is the latest pre-installation patch version and nnnnnn is the build number. Where You can install the pre-installation patch when the DataProtection-ACM is not registered with Secure Remote Services gateway by using SSH. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide... - Page 13 In the Port number field, specify the default port number 22. d. In the User name field, enter root e. In the Password field, enter Idpa_1234 f. Click Login. The following figure shows a sample WinSCP session configuration window. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide...
- Page 14 Messages be displayed on the screen during the installation process. The following message might be displayed, which you can ignore: “warning: file /usr/local/dataprotection/var/configmgr/server_data/ config/InfrastructureComponents_Template.xml: remove failed: No such file or directory” Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide...
-
Page 15: Launch The Appliance Configuration Manager
IDPA software, and configure the IDPA. To continue configuring the IDPA with the ACM, refer to the Integrated Data Protection Appliance DP4400 Getting Started Guide . This document explains common user tasks such as how to create backup policies and restore from backup. - Page 16 Information about software components and versions that are used in the IDPA product. IDPA training resources Video walkthroughs, demonstrations, and explanations of product features are available online. You can obtain additional IDPA training and information at https://education.emc.com. Dell EMC Integrated Data Protection Appliance DP4400 2.4 Hardware Installation Guide...
- Page 17 PARTICULAR PURPOSE. USE, COPYING, AND DISTRIBUTION OF ANY DELL SOFTWARE DESCRIBED IN THIS PUBLICATION REQUIRES AN APPLICABLE SOFTWARE LICENSE. Dell Technologies, Dell, EMC, Dell EMC and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be the property of their respective owners. Published in the USA.
