UG-1688
Table 2. Link Options for the P2_ Header (All Links are Inserted by Default)
Pin No.
Position
1, 2
Inserted
Not inserted
3, 4
Inserted
Not inserted
5, 6
Inserted
Not inserted
7, 8
Inserted
Not inserted
9, 10
Inserted
Not inserted
11, 12
Inserted
Not inserted
13, 14
Inserted
Not inserted
15, 16
Inserted
Not inserted
Function
Connects the FAULT signal from the
Disconnects the FAULT signal from the
Connects the RESET signal from the
Disconnects the RESET signal from the
Connects the LDAC signal from the
Disconnects the LDAC signal from the
Connects the SCLK signal from the
Disconnects the SCLK signal from the
Connects the SDO signal from the
Disconnects the SDO signal from the
Connects the SDI signal from the
Disconnects the SDI signal from the
Connects the SYNC signal from the
Disconnects the SYNC signal from the
Connects the PWRGD signal from the
Disconnects the PWRGD signal from the
EVAL-ADFS5758SDZ
SDP-S
to the MGPO3 pin on the ADP1031-1.
SDP-S
to the MGPO3 pin on the ADP1031-1.
SDP-S
to the MGPI2 pin on the ADP1031-1.
SDP-S
to the MGPI2 pin on the ADP1031-1.
SDP-S
to the MGPI1 pin on the ADP1031-1.
SDP-S
to the MGPI1 pin on the ADP1031-1.
SDP-S
to the MCK pin on the ADP1031-1.
SDP-S
to the MCK pin on the ADP1031-1.
SDP-S
to the MI pin on the ADP1031-1.
SDP-S
to the MI pin on the ADP1031-1.
SDP-S
to the MO pin on the ADP1031-1.
SDP-S
to the MO pin on the ADP1031-1.
SDP-S
to the MSS pin on the ADP1031-1.
SDP-S
to the MSS pin on the ADP1031-1.
SDP-S
to the PWRGD pin on the ADP1031-1.
SDP-S
to the PWRGD pin on the ADP1031-1.
Rev. 0 | Page 4 of 20
