EVAL-ADFS5758SDZ
Reference Designator
R4
R41, R42, R43
R5
R6
R7
R8
R9
R12
R37
S2
T1
TP1, TP2
U1
U2
U4
U5
Table 6. Bill of Materials (Uninserted Components)
Reference Designator
C18
C27
R19, R32, R35
R36
User Guide
Description
Resistor, precision, thick film, chip
Resistor, chip, SMD
Resistor, precision, thick film, 0603
Resistor, precision, thick film, R0603
Resistor, film, SMD, 0603
Resistor, thick film, chip
Resistor, thin film, precision
Resistor, thin film, chip, high reliability
Resistor, precision, thin film, chip
Switch, tiny, washable, toggle switches
Flyback transformer, EPX6, surface-
mount transformer (SMT)
Connector, PCB test point, green
3-channel, isolated micropower
management unit, seven digital isolators
IC, 32 kb serial electrically erasable
programmable read only memory
(EEPROM)
Ultralow noise, high accuracy voltage
reference
16-bit, current and voltage output DAC,
dynamic power control, HART®
connectivity
Description
Capacitor, ceramic, X7R
Capacitor, ceramic, X7R, general-purpose
Resistor, thick film, chip
Resistor, precision, thick film, chip
Manufacturer
Yageo
Murata
Multicomp
Panasonic
Rev. 0 | Page 19 of 20
Manufacturer Part Number
Panasonic ERJ-1GNF1003C
Vishay CRCW06030000Z0EA
Panasonic ERJ-3EKF5903V
Panasonic ERJ-3EKF1822V
Multicomp MC0063W0603139K
Vishay CRCW0603715KFKEA
TE Connectivity RN73C1J13K7BTG
Panasonic ERA-6AEB202V
TE Connectivity CPF0603B20RE1
Apem Components TL39P0050
Wurth Elektronik 750316743
Vero Technologies 20-313138
Analog Devices ADP1031ACPZ-1-R7
Microchip 24LC32A/SN
Technology
Analog Devices ADR4525BRZ
Analog Devices ADFS5758BCPZ-RL7
Part Number
CC0603KRX7R9BB103
GRM188R71A225KE15D
MC0063W06031100K
ERJ-6ENF2000V
UG-1688
