Digilent Eclypse Z7 Hardware Reference Manual page 30

Function Designator
ACT J3/LD2
The Zynq incorporates two independent Gigabit Ethernet Controllers. They implement a
10/100/1000 half/full duplex Ethernet MAC. Of these two, GEM 0 can be mapped to the
MIO pins where the PHY interfaces. Since the MIO bank is powered from 1.8V, the
RGMII interface uses 1.8V HSTL Class 1 drivers. For this I/O standard an external
reference of 0.9V is provided in bank 501 (PS_MIO_VREF). Mapping out the correct
pins and configuring the interface is handled by the Eclypse Z7 Vivado board files.
Although the default power-up configuration of the PHY might be enough in most
applications, the MDIO bus is available for management. The RTL8211E-VL is assigned
the 5-bit address 00001 on the MDIO bus. With simple register read and write
commands, status information can be read out or configuration changed. The Realtek
PHY follows industry-standard register map for basic configuration.
The RGMII specification calls for the receive (RXC) and transmit clock (TXC) to be
delayed relative to the data signals (RXD[0:3], RXCTL and TXD[0:3], TXCTL). Xilinx
PCB guidelines also require this delay to be added. The RTL8211E-VL is capable of
inserting a 2ns delay on both the TXC and RXC so that board traces do not need to be
made longer.
On an Ethernet network each node needs a unique MAC address. To this end, the one-
time-programmable (OTP) region of the Quad-SPI flash has been programmed at the
factory with a 48-bit globally unique EUI-48/64™ compatible identifier. The OTP
address range [0x20;0x25] contains the identifier with the first byte in transmission byte
order being at the lowest address. Refer to the
on how to access the OTP regions. When using Petalinux, this is automatically handled
in the U-boot boot-loader, and the Linux system is automatically configured to use this
unique MAC address. The identifier is also printed on a sticker found on the top-side of
the Eclypse Z7 right next to the mode jumper (JP5) and above the headphone output
jack.
For getting started using the ethernet port in a bare-metal application, Xilinx provides a
lwip TCP/IP stack that can be automatically generated in Xilinx SDK along with an echo
server example. When using the Eclypse Z7 with a Petalinux generated embedded
Linux system, the ethernet port will automatically appear as a network device typically
named eth0. See the Petalinux and Xilinx SDK documentation for more information.
For more low-level information on using the Zynq-7000 Gigabit Ethernet MAC, refer to
the Xilinx Zynq Technical Reference Manual.
State
Blinking
Description
Transmitting or Receiving
Flash memory datasheet for information
