Digilent Eclypse Z7 Hardware Reference Manual page 12

Net Upstream
Name Net Name
VCC1V0 VIN12V0
DDR1V35 VIN12V0
DDRVTT VIN12V0
VCC3V3 VIN12V0
VCC4V3 VCC5V0
VADJA VIN12V0
VADJB VIN12V0
VADJC VIN12V0
The power budget of VCC5V0 is shared by the SYZYGY ports, USB OTG VBUS, RGB
LEDs, and Case Fan. As such, the actual maximum current achievable by each
peripheral varies with the Eclypse Z7's system configuration. Under worst-case
conditions, VCC5V0 is capable of outputting a minimum of 3A of continuous current. In
this scenario, 1A is budgeted for each Zmod
Power Power
IC Type IC Label
Buck IC27
Buck IC25
LDO IC21
Buck IC25
LDO IC26
Buck IC27
Buck IC27
Buck IC25
Min/Typ/Max Max.
Voltage Current
1.0V +-5% 1A
1.35V +-5% 2A
0.675V +-5% 0.45A
3.3V +-5% 3.3A
4.3V +-5% 0.3A
1.2V to 3.3V; +- 1.8A
5%
1.2V to 3.3V; +- 1.8A
5%
2.5 to 5.5V; +- 0.3A
5%
Major Devices and
Connectors
Case Fan
Zynq, Ethernet, USB
OTG, USB
JTAG/UART, microSD
Zynq, DDR3L
DDR3L
Zynq, Zmods, Pmods,
USB OTG, USB
JTAG/UART, microSD
Pmods
FPGA, Zmod Port A
FPGA, Zmod Port B
FPGA Fan
