Digilent Eclypse Z7 Hardware Reference Manual page 2

Features
•
Zynq-7000 APSoC (XC7Z020-1CLG484C)
o
667 MHz dual-core Cortex-A9 processor
o
DDR3L memory controller with 8 DMA channels and 4 High Performance AXI3
Slave ports
o
High-bandwidth peripheral controllers: 1G Ethernet, USB 2.0, SDIO
o
Low-bandwidth peripheral controllers: SPI, UART, CAN, I2C
o
Programmable from JTAG, Quad-SPI flash, and microSD card
o
Programmable logic equivalent to Artix-7 FPGA
•
Memory
o
1 GiB DDR3L with 32-bit bus @ 1066 MT/s
o
16 MB Quad-SPI Flash with factory programmed 128-bit random number and 48-
bit globally unique EUI-48/64™ compatible identifier
o
microSD card slot
•
Power
o
Powered from external 12V 5A supply
o
Platform MCU for configuration of adjustable power supplies and temperature
management
•
USB and Ethernet
o
Gigabit Ethernet PHY
o
USB-JTAG programming circuitry
o
USB-UART bridge
o
USB micro AB port with USB 2.0 PHY with Host/Device/OTG capabilities
•
Zmod Ports
o
2 ports following the SYZYGY Standard interface specification
o
Compatible with a variety of SYZYGY pods, allowing for a wide variety of
applications
o
Dedicated differential clocks for input and output
o
8 differential I/Os per port
o
16 single-ended I/Os per port
o DNA interfaces connected to Platform MCU allowing for various auto-negotiated
power supply configurations
•
Pmod Ports
o 2 twelve-pin ports for a total of 16 FPGA-connected I/Os
o
High speed voltage translation and protection circuitry
•
User GPIO
o
2 push-buttons
o
2 RGB LEDs
