PARTS LIST

ITEM QTY REFERENCE
1
Required Circuit Components
1 1 U1
2 3 C8, C9, C10
3 6 R1, R2, R4, R5, R11, R75
Additional Demo Board Circuit Components
4 1 C11
5 4 C12, C16, C17, C39
6 2 C14, C15
7 2 C48, C56
8 1 C58
9 1 C59
10 1 D1
11 1 D2
12 1 Q1
13 3 R3, R6, R7
14 1 R8
15 20 R9, R18, R35, R36, R37, R38, R39, R40, R41, R43,
R44, R45, R46, R47, R48, R49, R61, R63, R64, R70
16 1 R10
17 3 R12, R13, R14
18 15 R15, R16, R42, R50, R51, R52, R53, R54, R55, R56,
R57, R58, R59, R60, R62
19 14 R17, R20, R21, R22, R23, R25, R26, R27, R28, R30,
R31, R32, R33, R65 (OPT)
20 7 R19, R24, R29, R34, R72, R73, R74
21 4 R66, R67, R68, R69
22 1 R71
23 2 SW1, SW2
24 1 SW3
25 1 U2
26 1 U3
Hardware—For Demo Board Only
27 1 J1
28 1 J2
29 1 J3
30 1 J4
31 1 J6
32 5 JP2-SH, JP3-SH, JP4-SH, JP5-SH, JP6-SH
33 4 MTG1, MTG2, MTG3, MTG4
34 18 TP01, TP02, TP03, TP04, TP05, TP06, TP07, TP08,
TP09, TP10, TP11, TP12, TP13, TP15, TP16, TP17,
TP18, TP19
35 0 OPTIONAL
Notes:
1. Required Circuit Components are those parts that are required to implement the circuit function.
2. Additional Demo Board Circuit Components are those parts that provide added functionality for the demo board but are not required in the actual circuit.
PART DESCRIPTION
IC 8-CH PWR SYSTEM MANAGER 64-QFN
CAP CERM 0.1µF 16V 20% X7R 0603
RES 10k 1/10W 5% 0603 SMD
2
CAP CERM 0.1µF 16V 20% X7R 0603
CAP CERM 10nF 50V 10% X7R 0603
CAP CERM 1µF 25V 10% X7R 1206
CAP CERM 0.47µF 16V 10% X5R 0603
CAP TANT 3.3µF 25V 20% SMD
CAP TANT 1µF 35V 20% SMD
LED RED DIFF SMD 0805
LED GREEN CLEAR 0805 SMD
MOSFET N-CH 60V 115MA SOT-23
RES 10k 1/10W 5% 0603 SMD
RES 75Ω 1/10W 5% 0603 SMD
RES 0.0Ω 1/10W 5% 0603 SMD
RES 200Ω 1/10W 1% 0603 SMD
RES 4.99k 1/10W 1% 0603 SMD
RES 100Ω 1/10W 1% 0603 SMD
RES 0.0Ω 1/8W 5% 0805 SMD
RES 0.0Ω 1/8W 5% 0805 SMD
RES 20k 1/10W 5% 0603 SMD
RES 10Ω 1/10W 1% 0603 SMD
SWITCH SLIDE SPDT 30V 0.2A PC MNT
SWITCH TACT MINI PB SPST SLV GWING
IC REG 3.3V 100MA LDO LN SOT23-5
IC, SERIAL EEPROM
CONN FEMALE 54POS DL 0.1 R/A TIN
CONN SOCKET 20 DUAL ROW RA
PIN HEADER 20 DUAL ROW RA
HEADER 14POS 2MM VERT GOLD
CONN HEADER 12POS 2MM STR DL PCB
CONN SHUNT 2MM 2POS GOLD BLACK
STAND-OFF NYLON 1/4" SNAP IN
TP TURRET SMALL FOR 0.063 HOLE
CONN HEADER BRKWAY (OPT)
DEMO MANUAL DC1540B
MANUFACTURER/PART NUMBER
LINEAR TECH: LTC2977IUP
AVX: 0603YC104MAT2A
VISHAY: CRCW060310K0JNEA
AVX: 0603YC104MAT2A
AVX: 06035C103KAT2A
AVX: 12063C105KAT2A
AVX: 0603YD474KAT2A
AVX: TAJC335M025R
KEMET: B45196H6105M109
PANASONIC: LN1271RTR
PANASONIC: LN1371SGTRP
FAIRCHILD: 2N7002_NL
VISHAY: CRCW060310K0JNEA
VISHAY: CRCW060375R0JNEA
VISHAY: CRCW06030000Z0EA
VISHAY: CRCW0603200RFKEA
VISHAY: CRCW06034K99FKEA
VISHAY: CRCW0603100RFKEA
VISHAY: CRCW08050000Z0EA
VISHAY: CRCW08050000Z0EA
VISHAY: CRCW060320K0JNEA
VISHAY: CRCW060310RFKEA
E-SWITCH: EG1218
C&K: KSR211GLFS
LINEAR TECH: LT1763CS8-3.3
MICROCHIP: 24LC025-I/ST
SULLINS: PPTC272LJBN-RC
MILL-MAX: 803-93-020-20-001
MILL-MAX: 802-40-020-20-001
MOLEX: 87831-1420
FCI: 98414-G06-12ULF
SAMTEC: 2SN-BK-G
KEYSTONE: 8831
MILL-MAX: 2308-2-00-44-00-00-
07-0
OPTION
