SCHEMATIC DIAGRAM
ITEM QTY REFERENCE
41 1 R85
42 2 R86, R87 (OPT.)
43 2 R88, R89
44 2 R91, R112
45 1 R111
46 1 Rc1
47 1 Rg1
48 1 Ron1
49 15 Ron2, R14, R15, R18, R24, R47, R60, R61,
R62, R63, R64, R65, R66, R72, R78
50 1 Rsns1
51 1 Rx1
52 8 U1, U2, U7, U12, U13, U15, U16, U17
53 1 U3
54 1 U10
55 1 U14
56 1 U18
Hardware – For Demo Board Only
57 18 E6, E7, E8, E9, E10, E11, E12, E13, E14, E15,
E16, E17, E18, E19, E20, E21, E30, E51
58 16 E35, E37, E39, E41, E43, E46, E49, E36, E38,
E40, E42, E44, E47, E50, E52, E53
59 1 J10
60 1 J11
61 1 JP1
62 2 JP2, JP3
63 3 JP1-SH, JP2-SH, JP3-SH
64 4 MTG1, MTG2, MTG3, MTG4
65 1 SW1
Notes:
1. Required Circuit Components are those parts that are required to implement the circuit function.
2. Additional Demo Board Circuit Components are those parts that provide added functionality for the demo board but are not required in the actual circuit.
DEMO MANUAL DC1540B
PART DESCRIPTION
RES 19.1k 1/10W 1% 0603 SMD
RES 0.0Ω 1/10W 5% 0603 SMD
RES 0.0Ω 1/10W 5% 0603 SMD
RES 60.4k 1/10W 1% 0603 SMD
RES 26.1k 1/10W 1% 0603 SMD
RES 68Ω 1/10W 5% 0603 SMD
RES 100Ω 1/10W 5% 0603 SMD
RES 24.3k 1/10W 1% 0603 SMD
RES, 10k 1/10W 1% 0603 SMD
RES 0.007Ω 1W 1% 2512 SMD
RES 10Ω 1/10W 5% 0603 SMD
IC, µMODULE, POWER SUPPLY
IC, µCIRCUIT
IC, µCIRCUIT
IC, HEX SCHMITT-TRIG INV 14TSSOP
IC, µCIRCUIT
TURRET, TESTPOINT
TURRET, TESTPOINT
CONN HEADER 54POS 0.100 R/A
15GOLD
TERMINAL BLOCK 5MM 2POS PCB
CONN HEADER 2MM MALE 1ROW 2POS COMM CON: 2802S-02G2
CONN HEADER 2MM MALE 1ROW 3POS COMM CON: 2802S-03G2
SHUNT 2MM
STAND-OFF NYLON 1/4" SNAP IN
SWITCH TOG. SPDT RT ANGLE
MANUFACTURER/PART NUMBER
VISHAY: CRCW060319K1FKEA
VISHAY: CRCW06030000Z0EA
VISHAY: CRCW06030000Z0EA
VISHAY: CRCW060360K4FKEA
VISHAY: CRCW060326K1FKEA
VISHAY: CRCW060368R0JNEA
VISHAY: CRCW0603100RJNEA
VISHAY: CRCW060324K3FKEA
VISHAY: CRCW060310K0FKEA
VISHAY: WSL25127L000FEA
VISHAY: CRCW060310R0JNEA
LINEAR TECH: LTM4603EV
LINEAR TECH: LTC6902IMS
LINEAR TECH: LTC4210-1CS6
TEXAS INST: SN74AHC14PWR
LINEAR TECH: LT1761ES5-3.3
MILL-MAX 2501-2-00-80-00-00-07-0
MILL-MAX 2308-2-00-80-00-00-07-0
FCI: 68021-254HLF
ON-SHORE-TECH: ED700/2
SAMTEC: 2SN-BK-G
KEYSTONE: 8831
C&K: E101MD1AQE
