DEMO MANUAL DC2393A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN
2 2 C1, C2
3 1 C3
4 1 C4
5 4 C5, C6, C7, C8
6 1 C9
7 1 D1
8 1 Z2
9 1 Z1
10 1 D2
11 1 R1
12 1 R2
13 1 R3
14 1 R4
15 1 R5
16 1 R6
17 1 T1
18 1 U1
Hardware: For Demo Board Only
1 4 E1 – E4
4
PART DESCRIPTION
CAP ., ALUM 18µF 80V
CAP ., 4.7µF, X7S, 100V, 10% 1210
CAP ., 1µF, X7R, 25V, 10% 1206
CAP ., 270pF, C0G, 50V, 5% 0805
CAP ., 100µF, X5R, 6.3V, 20% 1210
CAP ., 4.7nF, X7R, 250V, 10% 1812
DIODE, SBR1045D1, DPAK
DIODE, CMHZ5232B, SOD-123
DIODE, SMBJ51A, SMB
DIODE, CMMR1U-02, SOD-123F
RES., 402k, 1/10W, 1% 0603
RES., 32.4k, 1/10W, 1% 0603
RES., 100Ω, 1W, 1% 2515
RES., 309k, 1/8W, 1% 0805
RES., 100k, 1/10W, 1% 0603
RES., 10k, 1/10W, 1% 0603
TRANSFORMER, 750315125
IC LT8304 SO8E
TESTPOINT, TURRET, .094" PBF
MANUFACTURER/PART NUMBER
SUN ELECTRONIC INDUSTRIES CORPORATION, 80HVH18M
TDK, C3225X7S2A475K200AB
MURATA, GRM31MR71E105KA01L
MURATA, GRM2165C1H271JA01D
MURATA, GRM32ER60J107ME20L
MURATA, GA343DR7GD472KW01L
DIODES INC., SBR1045D1-13
CENTRAL SEMI., CMHZ5232B
DIODES INC., SMBJ51A-13-F
CENTRAL SEMI., CMMR1U-02
VISHAY, CRCW0603402KFKEA
VISHAY, CRCW060332K4FKEA
VISHAY, WSC2515100R0FEA
VISHAY, CRCW0805309KFKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060310K0FKEA
WURTH ELEKTRONIK, 750315125
LINEAR TECH., LT8304ES8E#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
