parts List
ITEM
QTY
REFERENCE
Required Circuit Components
1
11
C1, C2, C3, C5, C6, C11, C13, C15,
C18, C19, C20
2
5
C4, C36, C37, C40, C41
3
3
C7, C10, C21
4
0
C34(OPT.)
5
1
C31
6
0
C29, C35(OPT.)
7
1
C30
8
2
C32, C33
9
3
D1, D2, D3
10
1
J1
11
11
JP1–JP11
12
14
XJP1–XJP11
13
1
JP12
14
1
R1
15
1
R2
16
3
R3, R4, R5
17
3
R22, R25, R30
18
9
R11–R17, R23, R24
19
0
R26, R29, R31–R34(OPT.)
20
1
R27
21
1
R28
22
11
E1–E11
23
1
U1
24
1
U2
25
0
U3(OPT)
26
1
U4
27
1
U5
28
1
U6
29
1
U7
30
1
U9
31
1
U8
32
1
U10
33
1
U11
34
4
MH1–MH4
DEMO MANUAL DC1792A
PART DESCRIPTION
CAP ., X7R, 10µF , 10V, 20% 1206
CAP ., X7R, 0.1µF , 10V, 10% 0603
CAP ., X7R, 0.01µF , 10V, 10% 0603
CAP ., 0603
CAP ., C0G, 100pF , 10V, 10% 0603
CAP ., 1206
CAP ., C0G, 100pF , 10V, 10% 1206
CAP ., X7R, 1µF , 10V, 10% 1206
DIODE, BAT54C, SOT23
CONNECTOR, HD2X7-079
3-PIN 0.079 SINGLE ROW HEADER
SHUNT, .079" CENTER
0.1" JUMPER SHUNT, SOLDER DOWN
RES., CHIP , 88.7k, 1/16W, 1% 0603
RES., CHIP , 10.0k, 1/16W, 1% 0603
RES., CHIP , 4.99k, 1/16W, 1% 0603
RES., CHIP , 1k, 1/16W, 5% 0603
RES., CHIP , 10k, 1/16W, 5% 0603
RES., CHIP , 0603
RES., CHIP , 4.02k, 1/16W, 1% 0603
RES., CHIP , 10, 1/16W, 5% 0603
Turret, Testpoint
IC., LTC2756ACG, SSOP28
IC., LTC6655CHMS8-5, MSOP-8
IC., SO-8
IC., 24LC025, TSSOP-8
IC., LT1761ES5-5, SOT23-5
IC., LT1964ES5-5, SOT23-5
IC., LT1012ACS8, SO-8
IC., LT1360CS8, SO-8
IC., LTC2054CS5, TSOT23-5
IC., LT1761ES5-BYP , SOT23-5
IC., LTC6244CDD, 8-PIN 3 × 3, DD
STAND-OFF , NYLON 0.25"
MANUFACTURER/PART NUMBER
TDK, C3216X5R1A106M
AVX, 0603ZC104KAT2A
AVX, 0603ZC103KAT2A
AVX, 06033A101KAT2A
AVX, 1206ZC101KAT
AVX, 1206ZC105KAT2A
DIODE/ZETEX, BAT54CTA
MOLEX, 87831-1420
SAMTEC, TMM103-02-L-S
SAMTEC, 2SN-BK-G
SAMTEC, JL-100-25-T
VISHAY, CRCW060388K7KFEA
NIC, NRC06F1002TRF
NIC, NRC06F4991TRF
VISHAY, CRCW06031K00JNEA
NIC, NRC06J1002TRF
VISHAY, CRCW06034K02KFEA
VISHAY, CRCW060310R0JNEA
MILL-MAX, 2308-2-00-44
LINEAR, LTC2756ACG#TRPBF
LINEAR, LTC6655CHMS8-5#TRPBF
MICROCHIP , 24LC025 I /ST
LINEAR, LT1761ES5-5#TRPBF
LINEAR, LT1964ES5-5#TRPBF
LINEAR, LT1012ACS8#TRPBF
LINEAR, LT1360CS8#TRPBF
LINEAR, LTC2054CS5#TRPBF
LINEAR, LT1761ES5-BYP#TRPBF
LINEAR, LTC6244CDD#TRPBF
KEYSTONE, 8831(SNAP ON)
dc1792af
3
