DC1361B - CHANGING THE NOMINAL OUTPUT VOLTAGES
The Nominal V of any channel on the DC1361B can be
OUT
changed by changing the R
These are: R21, R26, R29, R38, R48, R67, R73, R79. See
Figure 9. The value for the R
R = 60.4k/((V /0.6) –1))
SET OUT
Figure 9. DC1361B Output Voltage Setting Resistor Locations
resistor from V to SGND.
SET FB
resistor is:
SET
DEMO MANUAL DC1540B
See also the LTM4603 datasheet Table 2. V
adjusted up to 5V. The other channels may be adjusted
up to 4V.
may be
OUT0
