DC1360B DETAILS - TOP SIDE
Table 3. DC1360B - Default Jumper Configuration. Use ASEL's to Select I
JP2
ASEL1
LO
Figure 6. DC1360B Top Side
2
JP3
JP4
ASEL0
Write-Protect
LO
ON
DEMO MANUAL DC1540B
C Address.
JP5
LTC2977 Write
Protect
OFF
JP6
Share_CLK
Installed
dc1540bf
9
