DEMO MANUAL DC547A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 15 C1, C4-C6, C10, C11, C13-C20, C23
2 1 C2
3 2 C3, C12
4 2 C7, C9
5 1 C8
6 2 C21, C22
7 9 E1-E9
8 7 JP1-JP7
9 2 JP8, JP9
10 9 SHUNTS FOR JP1-JP9
11 3 J1-J3
12 1 J4
13 1 RN1
14 2 R1, R2
15 2 R3, R4
16 2 R5, R6
17 1 R7
18 1 R8
19 1 R9
20 1 R10
21 1 U1
22 1 U2
23 1 U3
24 2 U4, U5
25 2 U6, U7
26 1 U8
27 1 U9
28 1 U10
29 1 U11
30 1 U12
31 1 U13
32 4 MTGS AT 4 CORNERS
33 4 MTGS AT 4 CORNERS
NOTES: UNLESS OTHERWISE SPECIFIED
1. ALL RESISTORS ARE IN OHMS.
2. INSTALL SHUNTS ON JP1,JP3-JP7 PIN 1 AND 2; ON JP2 PIN 2 AND 3;
ON JP8 PIN 1 AND 3, PIN 2 AND 4; ON JP9 PIN 1 AND 3, PIN 4 AND 6.
4
PART DESCRIPTION
CAP., X7R, 0.1µF, 16V
CAP., X7R, 1µF, 10V, 20%
CAP., X5R, 10µF, 6.3V, 20%, 1206
CAP., NPO, 100PF, 50V, 1206
CAP., NPO, 470PF, 100V,1206
CAP., NPO, 47PF, 50V
TP, TURRET, .094"
JMP, 1 × 3, .079CC
JMP, 2 × 3, .079CC
SHUNT, .079" CENTER
CONN, BNC 50Ω, PCB-VERTICADTL
CON, HDR, .1 × .1 CNTRS, 40PIN
RES, 2 × 4 ARRAY, CHIP, 330Ω, ISO
RES, CHIP 100, 1/16W, 5%,1206
RES, CHIP 2, 1/16W, 5%, 0603
RES, CHIP 402, 1/16W, 1%, 0603
RES, CHIP 20k, 1/16W, 5%, 0603
RES, CHIP 1M, 1/16W, 5%, 0603
RES, CHIP 51, 1/16W, 5%, 0603
RES, POT3321H, POT-3321H-MURATA
IC, LT1460DCS8-2.5, SO8
IC, OP AMP, SO8
IC, LTC1864LAIMS8, MSOP8
IC, MC74HC595ADT, TSSOP16
IC, MC74HC163AD, SO16
IC, MC74AC14DTR2, TSSOP14
IC, MC74AC00DTR2, TSSOP14
IC, LTC1799CS5, SOT23-5
IC, LT1121CST-3.3, SOT223
IC, MC74AC109DR2, SO16
IC, MC74AC32DTR2, TSSOP14
SCREW, #4-40, 1/4"
STANDOFF, NYLON HEX #4-40 1/2"
MANUFACTURER/PART NUMBER
AVX, 0603YC104MAT1A
AVX, 0805ZC105MAT1T
TAIYO YUDEN JMK316BJ106MLT
VITRAMON, VJ1206A101JXA
AVX, 12061A471JAT
AVX, 06035A470MAT1A
MILL-MAX, 2501-2
COMM-CON, 2802S-03-G1
COMM CON, 2202S-06-G2
COMM-CON, CCIJ2MM-138G
CONNEX, 112404
COMMCON, 3201S-40G1
CTS, 742-C083-331JTR-ND
AAC, CR18-101JM
AAC, CR16-2R0JM
AAC, CR16-4020FM
AAC, CR16-203JM
AAC, CR16-105JM
AAC, CR16-510JM
MURATA, PV32H103A01B00
LINEAR TECH., LT1460DCS8-2.5
TBD
LINEAR TECH., LTC1864LAIMS8
MOTOROLA, MC74HC595ADT
MOTOROLA, MC74HC163AD
ON SEMI., MC74AC14DTR2
ON SEMI., MC74AC00DTR2
LINEAR TECH., LTC1799CS5
LINEAR TECH., LT1121CST-3.3
ON SEMI., MC74AC109DR2
ON SEMI., MC74AC32DTR2
ANY
MICRO PLASTICS 14HTSP003
