Parts List - Linear Technology DC2015A Demo Manual

PARTS LIST

ITEM QUANTITY
42 1
43 1
44 1
45 1
46 1
47 1
48 1
49 1
50 1
51 1
ADDITIONAL DEMO BOARD CIRCUIT COMPONENTS
1 0
2 0
3 0
4 0
5 0
6 0
HARDWARE-FOR DEMO BOARD ONLY
1 8
2 4
3 2
REFERENCE PART DESCRIPTION
R30 Res., Chip 560Ω 0.10W 5% 0603
R32 Res., Chip 178Ω 0.125W 1% 0805
R33 Res., Chip 20k 0.25W 5% 1206
R37 Res., Chip 499Ω 0.10W 1% 0603
R39 Res., Chip 61.9k 0.10W 1% 0603
T1 Transformer, 8:4 / (w/4T Pri. Aux)
T2 Transformer, 1.25:1
U1 I.C., Converter Controller TSSOP20-FE20(16)/CB
U2 I.C., Converter Controller TSSOP20-FE20(16)/CB
FAB, 2015A_Rev3.pcb
C27,C28 Cap., 0603
D1 Schottky Diode SMA
D3 Diode, Common Cathode SOT-23
L2 Inductor
R9, R12 Res., 0805
R21, R22 Res., 0603
E1, E2, E3, E4, Turret, Testpoint
E5, E6, E7, E8
MH1-MH4 Standoff, Nylon 0.25"
Stencil (Top & Bottom)
DEMO MANUAL DC2015A
MANUFACTURER/PART #
Vishay CRCW0603560RJNEA
Vishay CRCW0805178RFKTA
Vishay CRCW120620K0JNED
Vishay CRCW0603499RFKEA
Vishay CRCW060361K9FKEA
Pulse PA0423
Pulse PA3493NL
Linear Tech. Corp. LT8310EFE#PBF
Linear Tech. Corp. LT8311EFE#PBF
Demo Circuit 2015A
Central Semi. Corp. CMSD2838
Coilcraft LPS4414 series
Mill Max 2501-2-00-80-00-00-07-0
Keystone, 8831 (Snap-On)
Stencil DC2015A
dc2015af
7
