Parts List - Linear Technology DC1709A Manual

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 SKT1
2 4 C11, C14, C16, C20
3 0 C12
4 1 C13
5 2 C15, C17
6 4 C18, C19
7 1 LED1
8 1 LED2
9 3 Q1, Q2, Q3
10 1 Q4
11 1 Q5
12 3 R19, R21, R28
13 8 R20, R23-R26, R29, R31, R33
14 1 R22
15 1 R27
16 3 R30, R34, R39
17 0 R32, R38
18 3 R35, R36, R37
19 1 U3
20 1 U2
21 2 JP1, JP2
22 1 J1
23 1 J2
24 13 TP1,TP2,TP3,TP4,TP5,TP6,TP7,
TP8,TP9,TP10,TP11,TP13
25 4 MTH1, MTH2, MTH3, MTH4
26 2 JP1, JP2
27 1
28 1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1709A
PART DESCRIPTION
6×6 QFN FLAT LEAD LIDDED THROUGH-HOLE
SOCKET
CAP., 0.10µF, 10%, 16V, X7R, 0603
CAP., CER, 10000pF, 25V, 10%, X7R, 0603, OPT.
CAP., 1µF, 16V, CERAMIC, X7R, 1206
CAP., 4.7µF, 6.3V, CERAMIC, X5R, 1206
CAP., TANTALUM, 1µF, 50V, 10%, SMD
LED, RED S-TYPE GULL WING, 2.03V, SMD
LED, GREEN S-TYPE GULL WING 2.03V, SMD
MOSFET P-CH, 20V, 580mA, SOT23-3
MOSFET N-CH, 60V, 115mA, SOT-23
MOSFET, N-CH, 30V, 5.1A, SC70-6
RES., 1.00kΩ, 1/8W, 1%, 0805, SMD
RES., 10.0kΩ, 1/10W, 1%, 0805, SM
RES., 100kΩ, 1/8W, 1%, 0805, SMD
RES., 0.50Ω, 1/3W, 1%, 0805, SMD
RES., 1.0Ω, 1/8W, 1%, 0805, SMD
RES., 1.0Ω, 1/8W, 1%, 0805, SMD, OPT.
RES., 4.99kΩ, 1/8W, 1%, 0805, SMD
IC., OVERVOLTAGE/OVERCURRENT PROTECTION
CONTROLLER
IC., EEPROM, 2KBIT, 400kHz, 8SOIC
HEADER, 0.079, SINGLE ROW, 3-PIN
CONN, HEADER, 14POS, 2mm, VERT GOLD
CONN, HEADER, 12POS, 2mm, 2ROW GOLD
TURRET, TERM SOLDER, 0.156", 0.066"L
SUPPORT POST NYLON SNAP-IN, 1/4"
SHUNT
STENCIL, TOP
FAB, PRINTED CIRCUIT BOARD
MANUFACTURER/PART NUMBER
PLASTRONICS, 40QN50S16060-B
AVX, 0603YC104KAT2A
AVX, 06033C103KAT2A
AVX, 1206YZ105KAT
TDK, C3216X5R0J475K
AVX, TAJC105K050RNJ
PANASONIC, LN1271RTR
PANASONIC, LN1371SGTRP
VISHAY, TP0101K-T1-E3
FAIRCHILD SEMICONDUCTOR, 2N7002
VISHAY, Si1470DH-T1-E3
VISHAY, CRCW08051K00FKEA
YAGEO, RC0805FR-0710KL
YAGEO, RC0805FR-07100KL
SUSUMU, RL1220S-R50-F
YAGEO, RC0805FR-071RL
YAGEO, RC0805FR-074K99L
LINEAR TECHNOLOGY, LTC4361CTS8-2#PBF
MICROCHIP, 24LC025-I/SN
SAMTEC, TMM-103-02-L-S
MOLEX, 87831-1420
FCI CONNECTOR CORP., 98414-G06-12ULF
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 8831
SAMTEC, 2SN-BK-G
STENCIL, DC1709A
DEMO CIRCUIT, 1709A
DC1709af
5
