Product Features and Specifications

Feature
PCB Size / Overall Size
Gigabit Ethernet
LVDS Video &
Backlight power
HDMI Video
DisplayPort Video
DVI Video
VGA
3.5mm Audio Connector
PMC / XMC Slots
Dual mode mSATA/MiniPCIe
MiniPCIe Only Slots
SIM Card Slots
USB 3.0 Ports
USB 2.0 Ports
SATA HDD connector
SATA HDD power connector
GPIO or Micro SD
Power Connector
Standard Serial
Console Serial Port
CMOS / RTC 3.3V Battery
Accessories
Operating Temperature
Power Input
Warranty and Support
[1]
Jumper Selectable.
Revision 0.03
Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Part Number: CCG007
15.000" x 7.500"
Maximum Top Side Component Height: 1.259"
3D STEP Model: download here
1 Stereo Input / 1 Stereo Output
4 Position screw terminal
8 x RS-232/485
1x RS232 basic port
Optional Cable Kit ( SATA HDD/Power Cable, VGA, Serial)
-40 to +85 Celsius
Wide Input (+6V to +36V)
Limited two-year warranty and free technical support
2
Y
Y
Y
Y
Y
2
2
2
4
4
6
2
2
[1]
Y
[1]
[1]
Y
7
