Connector Summary

Designator Connector
J11A, J12A PMC
J11B, J12B PMC
J15A XMC
J15B XMC
P1 440-pin Board Stacking Connector
P2A SATA Vertical Locking
P2B SATA Vertical Locking
P3A 4-pin 0.1" keyed header
P3B 4-pin 0.1" keyed header
P4 DVI D-Sub
P5 2 x 3.5mm Phono Jack
P6 20-pin 1mm pitch Hirose DF19G
P7 2-pin JST SM02B
P8 3-pin 0.1" keyed header
P9A SIM Card Socket
P9B SIM Card Socket
P10A SIM Card Socket
P10B SIM Card Socket
P11 2 x 20-pin 0.1" header
P12 2 x 20-pin 0.1" header
P13 2 x 5-pin 2mm header
P14 2 x 10-pin 2mm header
P16 4-pin 5mm Pitch Terminal Block
P17 2032 Coin Batter Socket
P18 3-pin 0.1" keyed header
P20 2 x 5-pin 0.1" header
P21A USB / RJ45
P21B USB / RJ45
P22 DP / HDMI
P23A USB
P23B USB
P24 3-pin 0.1" keyed header
U11A miniPCIe
U11B miniPCIe
U13A miniPCIe
U13B miniPCIe
10
Description
PMC Slot-0 Connector
PMC Slot-1 Connector
XMC Slot-0 Connector
XMC Slot-1 Connector
COM Express Type-6 Connector
SATA Channel 2
SATA Channel 3
SATA Power Channel 2
SATA Power Channel 3
DVI Video
Audio Input/Output
LVDS Video Connector
LVDS Backlight Power Connector
Case Fan-1 (+12V)
miniPCIe Slot-2 SIM Card Socket
miniPCIe Slot-3 SIM Card Socket
miniPCIe Slot-0 SIM Card Socket
miniPCIe Slot-1 SIM Card Socket
RS-232/485 - PORTS 1-4
RS-232/485 - PORTS 5-8
VGA Video Connector
GPIO / RS-232 Console Connector
Input Power Connector
RTC Battery Socket
CPU Fan Connector (+12V)
Internal USB 2.0 Ports 6 & 7
USB3.0 Ports 0&1 and GBE 0
USB3.0 Ports 2&3 and GBE 1
Display Port and HDMI
USB 2.0 Ports
USB 2.0 Ports
Case Fan-2 (+12V)
miniPCIe-2 Connector
miniPCIe-3 Connector
miniPCIe-0 / mSATA-0 Connector
miniPCIe-1 / mSATA-1 Connector
Revision 0.03
