Air velocity meaursurement screen

Composite screens
Air velocity meaursurement screen
There are a couple quick steps to ensure air velocity is setup and that
the AirProbe is attached before measuring.
1. The air velocity setting is enabled in Setup /AUX/Air Velocity
2. Connect the AirProbe bracket attachment to the backside of the
3. Turn AirProbe switch to On.
4. Navigate to the Air Velocity measurement screen using the
5. To log air velocity data, press the Run/Stop key.
AirProbe bracket
attachment
Output
*Pull back rubber
covering in order
to plug in cable.
Air velocity
measurement
screen

Figure 5-11: Attaching AirProbe and measuring Air velocity

screen. (See "Air Velocity" Setup in Chapter 3 for more details.)
EVM. Attach the AirProbe to the bracket. Next, plug in AirProbe
plug from the AirProbe to the digital output on the instrument.
(See AirProbe output below.) (Note: it is optional to attach the
AirProbe to the bracket on the instrument.)
Arrows.
Connect AirProbe to
the back housing (two
inlets located near the
air flow outlet. See air
flow diagram on
previous page. )
