Electric driven actuator KBZ Series
High-tact
Allowable max. speed of 800 mm/s
Equipped with the servo motor
Servo motor allows high speed, high acceleration/deceleration, and
greater weight capacity
Absolute specification
Absolute specification without return-to-home
Small controller
Developed to target the smallest size and lowest price
Electric driven actuator ESSD/ELCR Series
Space saving
Built-in controller eliminates the need for controller installation
space and wiring
Installable like a pneumatic cylinder
Design which can imagine a pneumatic cylinder as it is, including
appearance configuration, various controls and usage
Motion control at will
Three control modes, speed & acceleration control and positioning
completion width (imposition) can be set
Easy teaching
Easy setting with five buttons, enabling direct teaching
AX6000M
Catalog no. CC-1102A
Catalog no. CC-1002A
