AX6000M
Related products
Electric driven actuator ERL2/ESD2 Series
Number of alignment points
"63 points alignment" for general purpose is added to conventional
"7 points alignment"
Easy setting tool
As well as teaching pendant (ETP2), added easy computer setting
software (E Tools)
Perfect compatibility
"Perfect compatibility" enables free combination between actuator
and controller
ABSODEX Quick response type
AX1000T, AX2000T, AX4000T Series
Ample actuators
12 types of actuators are available from 6 to 1000 N•m.
5 options for interface
5 types (Parallel I/O (NPN, PNP), CC-Link, DeviceNet, PROFIBUS-
DP) are available for driver interface.
Electric driven actuator motor-less type
Ball screw driven ETS Series
Motor size: 8 types, lead: 7 types, motor installation directions:
5 types
Motor you have been familiar with is installable
Installing specifications for home position sensor and limit sensor
are selectable
Stroke length selection range: 100 - 1500 mm (in 50 mm pitch)
Wide range of application with Max. load capacity of 150 kg, and
max. speed of 2000 mm/s.
Ball screw driven low particle generation
specifications ETS Series
Low particle generation is achieved with full cover structure based
on ETS Series and suction port.
Motor size: 7 types, lead: 7 types, motor installation directions:
5 types
Motor you have been familiar with is installable
Installing specifications for home position sensor and limit sensor
are selectable
Stroke length selection range: 100 - 1500 mm (in 50 mm pitch)
Wide range of application with Max. load capacity of 150 kg, and
max. speed of 2000 mm/s.
Belt driven ETV Series
Belt driven type based on ETS Series.
Stroke length selection range is between 100 - 3500 mm (in 50 mm
pitch). Also the max speed is 2000 mm/s. Long stroke length and
high speed is achieved.
Motor size: 6 types, motor installation directions: 6 types
Motor you have been familiar with is installable
19
Series
Catalog no. CC-1219A
Catalog no. CC-995A
Catalog no. CC-1165A, CC-1216A, CC-1217A
