What is the Carrier® ChillerVu™?
Carrier® ChillerVu™ specifications
Driver
Maximum number of
control programs*
Maximum number of
BACnet objects*
Maximum number of third-
party integration points
using Snap*†
* Depends on available memory
† BACnet third-party integration points are not counted.
Power
10/100 BaseT Ethernet
Port
BACnet port S1
Port S2
Option Comm
Rnet port
Local Access port
Xnet Remote Expansion
port
Inputs
Carrier® ChillerVu™
(OPN-PSM-MPCXPE)
Installation and Start-up Guide
drv_psmio_6.02.028 or later
999
12000
1000
24 Vac ±10%, 50–60 Hz
50 VA power consumption
26 Vdc (25 V min, 30 V max), 23 W
Single Class 2 source only, 100 VA or less
For communication on the Ethernet at 10 or 100 Mbps, half duplex
For LAN, BACnet/Ethernet, BACnet/IP, and/or Modbus TCP/IP communications
For communication with the controller network using BACnet ARC156 (156 kbps)
or BACnet MS/TP (9600 bps – 76.8 kbps)
For communication on EIA-232 or EIA-485 (2-wire or 4-wire)
Network protocol selectable for:
• CCN
•
Modbus
•
LonWorks Option Card
•
LonWorks SLTA
For LonWorks Option Card
The standard control programs that are included with the Carrier® ChillerVu™
library do not use communicating sensors or the Equipment Touch.
A custom control program could allow you to use and connect the following to the
Rnet port:
•
Up to 15 ZS sensors (5 per control program)
•
One Wireless Adapter that communicates with up to 15 wireless sensors
•
One Equipment Touch
•
Up to 4 SPT Standard sensors and one SPT Plus, SPT Pro, or SPT Pro-F sensor
NOTE ZS sensors, a Wireless Adapter, and an Equipment Touch can share the
Rnet, but not SPT sensors.
For system start-up and troubleshooting
For communication with expanders MPC Open XPIO48 and/or MPC Open
XPIO816. Up to 6 expanders with a maximum of 164 points between the Carrier®
ChillerVu™ and the expanders.
12 inputs, configurable for 0–5 Vdc, 0–10 Vdc, 0–20 mA, RTD, thermistor, or dry
contact
