NOTE: Read the entire instruction manual before starting the
installation.
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2-Speed Indoor Fan Motor System . . . . . . . . . . . . 2
Identifying Factory Option . . . . . . . . . . . . . . . . . . . . . 2
System Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Fan System Option . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating Fan for Test and Balance . . . . . . . . . . . . 24
REMOTE KEYPAD REFERENCE . . . . . . . . . . . . . . . 25
Variable Frequency Drive . . . . . . . . . . . . . . . . . . . . . 25
VFD REMOTE KEYPAD . . . . . . . . . . . . . . . . . . . . . . . 26
ACH550/ACS320 VFD Modes . . . . . . . . . . . . . . . . . . 26
ACH550/ACS320 VFD Diagnostics . . . . . . . . . . . . . 29
Correcting Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Correcting Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Reset After Using Start-Up Assistant . . . . . . . . . . . 32
ACH580 VFD Modes . . . . . . . . . . . . . . . . . . . . . . . . . 34
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53480189-01
Installation Instructions
P/N CRDISKIT001A00 and CRDISKIT003A00
Printed in U.S.A.
Variable Frequency Drive (VFD)
For 2-Stage Cooling Units, 6-30 Tons
ACH580 VFD Diagnostics . . . . . . . . . . . . . . . . . . . . .37
Correcting Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Page
Correcting Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Control Panel Cleaning . . . . . . . . . . . . . . . . . . . . . . .40
Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . .40
APPENDIX A - VFD Remote Keypad Parameters 41
CONFIGURATION OVERRIDE HAZARD
Do not use start-up assistant or first start assistant on this VFD
application! Use of the assistant will override the factory VFD
configurations!

SAFETY CONSIDERATIONS

Improper
installation,
maintenance, or use can cause explosion, fire, electrical shock or
other conditions which may cause personal injury or property
damage. Consult a qualified installer, service agency, or your
distributor or branch for information or assistance. The qualified
installer or agency must use factory-authorized kits or accessories
when modifying this product. Refer to the individual instructions
packaged with the kits or accessories when installing.
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloths for brazing operations and have a fire
extinguisher available. Read these instructions thoroughly and
follow all warnings or cautions attached to the unit. Consult local
building codes and appropriate national electrical codes (in
U.S.A., ANSI/NFPA70, National Electrical Code (NEC); in
Canada, CSA C22.1) for special requirements.
It is important to recognize safety information. This is the safety-
alert symbol
instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAUTION,
and NOTE. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
Form IIK-CRDISKIT01-05
Pg 1
Remote Keypad Kit
CAUTION
adjustment,
alteration,
. When you see this symbol on the unit and in
9-23
Replaces: IIK-CRDISKIT01-04
