CRDISKIT002A00
Multi---Speed VFD Display Kit
For Danfoss Controller
For Use with 48/50LC 07---26 Units
SAFETY CONSIDERATIONS
Improper installation, adjustment, alteration, service,
maintenance, or use can cause explosion, fire, electrical
shock or other conditions which may cause personal
injury or property damage. Consult a qualified installer,
service agency, or your distributor or branch for
information or assistance. The qualified installer or
agency must use factory- - authorized kits or accessories
when modifying this product. Refer to the individual
instructions packaged with the kits or accessories when
installing.
Follow all safety codes. Wear safety glasses and work
gloves. Use quenching cloths for brazing operations and
have a fire extinguisher available. Read these instructions
thoroughly and follow all warnings or cautions attached to
the unit. Consult local building codes and appropriate
national electrical codes (in USA, ANSI/NFPA70,
National Electrical Code (NEC); in Canada, CSA C22.1)
for special requirements.
It is important to recognize safety information. This is the
safety- - alert symbol
. When you see this symbol on the
unit and in instructions or manuals, be alert to the
potential for personal injury.
Understand the signal words DANGER, WARNING,
CAUTION, and NOTE. These words are used with the
safety- - alert symbol.
DANGER identifies the most serious hazards which will
result in severe personal injury or death. WARNING
signifies hazards which could result in personal injury or
death.
CAUTION is used to identify unsafe practices, which
may result in minor personal injury or product and
property damage.
NOTE is used to highlight suggestions which will result in
enhanced installation, reliability, or operation.
Installation Instructions
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could cause personal
injury or death.
Before performing service or maintenance operations
on unit, always turn off main power switch to unit and
install lock(s) and lockout tag(s). Unit may have more
than one power switch. Ensure electrical service to
rooftop unit agrees with voltage an amperage listed on
the unit rating plate.
CAUTION
!
CUT HAZARD
Failure to follow this caution may result in personal
injury.
Sheet metal parts may have sharp edges or burrs. Use
care and wear appropriate protective clothing, safety
glasses and gloves when handling parts and servicing
air conditioning equipment.
Table 1 – VFD Remote Keypad Kit Contents
COMPONENT NAME
Hand Held VFD Key Pad/Display
Cable, 10 ft. (3 meter)
Screws
Instructions VFD Display
1
QTY
1
1
4
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CRDISKIT002A00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier CRDISKIT002A00

  • Page 1 CRDISKIT002A00 Multi---Speed VFD Display Kit For Danfoss Controller For Use with 48/50LC 07---26 Units Installation Instructions SAFETY CONSIDERATIONS WARNING Improper installation, adjustment, alteration, service, ELECTRICAL SHOCK HAZARD maintenance, or use can cause explosion, fire, electrical shock or other conditions which may cause personal Failure to follow this warning could cause personal injury or property damage.
  • Page 2 Variable Filter - used on Frequency 575V units only! Drive (VFD) C13111 Fig. 1 - - VFD Location in 48/50LC Size 07 Units Variable Frequency Filter - used on Drive (VFD) 575V units only! C13229 Fig. 2 - - VFD Location in 48/50LC Size 08- - 12 Units...
  • Page 3 230V/460V 575V ONLY C13209 Fig. 3 - - VFD Location in 48/50LC Size 14- - 26 Units...
  • Page 4 Multi- -Speed VFD Display Kit Navigation Keys and Status LEDs: The Navigation keys and Status LEDs are detailed in the following table. (Field- - Installed Option) Com. The VFD Display Kit (CRDISK002A00) consists of two main components; the VFD remote keypad and the VFD remote keypad cable (see Fig.
  • Page 5 At the first power up the LCD displays the Select Multi- - Speed VFD display kit (PN: CRDISKIT002A00). Language screen. The default setting is English. To change the language, press the OK key and use the Y and B keys to scroll to the desired language and then press OK.
  • Page 6 3. Clearing Alarm 060: External Interlock: a. Press the Menu key twice to position the B(tri- angle icon) over Main Menu; the display Select language English changes to - - [0] English 0--- ** Operation / Display SETUP 1 1--- ** Load and Motor Status Quick Main...
  • Page 7 m. Press B(Down Arrow) once to display the 5. Entering Motor Data: following - - a. Press the Menu key to move the B(triangle icon) so it is positioned over Main Menu. The 1-25 Motor Nominal Speed display show the following - - 1740rpm 0--- ** Operation / Display n.
  • Page 8 l. Press B(Down Arrow) once, the following f. Press the Back key until the following display display appears - - appears - - 1-82 Min Speed for Functio… 3--- 0* Reference Limits 1.0 Hz 3--- 1* References m. Press OK to highlight the number and then use g.
  • Page 9 f. Press OK again to highlight the bottom row and 10. Setting Digital Inputs: use the Y and B (Up and Down Arrow) keys to a. Press the Back key until the following display select 10.00s. Press OK again to set the selected appears - - Ramp Down Time.
  • Page 10 Press the Auto On key before disconnecting the This is possible, for instance, in 1- - 90 Motor Thermal VFD Remote Keypad from the variable Protection. After an alarm or trip, the motor carrier on frequency drive. coasting, and the alarm and warning flash on the VFD.
  • Page 11 Earth Fault Discharge from output phases to ground. Control Voltage Fault 24 V DC may be overloaded. VDD1 Supply Low Control voltage low. Please contact your local Carrier representative. AMA Calibration failed Contact your local Carrier representative. AMA Unom,Inom The setting of motor voltage, motor current and motor power is presumably wrong.
  • Page 12 Pwr Card Temp The temperature sensor on the power card is either too hot or too cold. Illegal power selection configuration Internal fault. Contact your local Carrier representative. Drive initialized All parameter setting are initialized to default settings. Auto DC Braking The drive is auto DC braking.
  • Page 32 Catalog No: IIK---CRDISKIT02---01 Copyright 2013 Carrier Corp. D 7310 W. Morris St. D Indianapolis, IN 46231 Edition Date: 06/13 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations. Replaces:New...
