Setting up a VPLEX Local implementation
Moving your
connection
36 EMC VPLEX with GeoSynchrony 4.2 Installation and Setup Guide
4. From the VPlexcli prompt, type the following to configure the IP address of the
management server's public Ethernet port:
management-server set-ip -i <IP_address>:<netmask> -g <gateway> eth3
5. Type the following command, and confirm that the output shows the correct
information:
ll /management-server/ports/eth3
Output example:
Name Value
-------- -------------
address 10.243.48.65
gateway 10.243.48.1
net-mask 255.255.255.0
6. For the remaining setup tasks, you can leave your laptop connected directly to the
management server, or you can move to a more-comfortable location and
reconnect to the management server over the customer network:
• If you are leaving the laptop connected to the management server, proceed to
"Task 4: Launch the EZ-Setup Wizard" on page
• If you want to connect over the network, proceed to
connection."
If you want to connect over the customer network to perform the remaining setup
tasks, follow these steps:
1. Type the following command at the VPlexcli prompt, and again at the Linux shell
prompt:
exit
2. Disconnect the red service cable from your laptop and the management server,
and return the cable to its location on the inside of the cabinet.
3. Prepare for connection to the customer network:
• If you are connecting to the network from your laptop, set the laptop to an IP
address on the network.
• If you are connecting from a different PC (or similar device):
a. Restore your laptop to the settings it had before you began this procedure
(including re-enabling any network cards).
b. Verify that PuTTY or other Telnet/SSH client is installed on the device, and
install it if necessary.
c. Set the device to an IP address on the customer network.
4. Launch PuTTY.exe, and configure PuTTY as shown in
38.
"Moving your
Figure 24.
