Director LEDs
Steady green
Amber during POST, off
during normal operation
SPS and director LEDs
Figure 15
8. If the cluster is dual-engine or quad-engine:
a. Verify that the Online LED on each UPS (shown in
(green), and that none of the other three LEDs shown in
illuminated.
If the Online LED on either UPS is not illuminated, push the power button,
and verify that the LED is illuminated before proceeding.
UPS, front view
Figure 16
b. Verify that neither circuit breaker (shown in
triggered. If a circuit breaker has triggered, press it to reseat it.
UPS, rear view
Figure 17
SPS LEDs:
On-line Enabled (LED on) or On-line Charging (LED flashing)
On-Battery
Replace Battery
Internal Check
On battery LED
Figure
Figure 16
Online LED
Overload LED
Replace battery LED
Power button
Figure
17) on either UPS has
Circuit breakers
Installing a cluster
Installing the Hardware
Zep-011a
16) is illuminated
is
sym-001521z
Zep-036a
29
