Installing the Device
2.5.3 Wiring Examples
4.
5.
2.5.3
Wiring Examples
The following illustrate how to connect single and dual power supplies to the device.
20
For pluggable terminal blocks, install the safety cover.
1
2
Figure 2.12
Assembling the Safety Cover
Connect the ground terminal on the power source to the ground terminal on the
device.
M3 Screw
1
M3 Ring Lug
2
Figure 2.13
Chassis Ground Connection
2
1
RUGGEDCOM RST2228
Installation Manual, 08/2020, C79000-G8976-1359-10
