Omcan MS-IT-0300-V, MS-0330-V,MS-0350-V, MS-0370-V Instruction Manual page 40

Parts Breakdown
Model MS-IT-0370-V
Item No. Description
32547 Housing for 370TCV
32548 Guide Plate for 370TCV
32549 Guide Plate Support for 370TCV
32550 Guide Plate Shaft for 370TCV
32551 Bracket for 370TCV
32552 Index Knob for 370TCV
32553 Index Knob Bushing for 370TCV
32554 Wavy Washer for 370TCV
32555 Cam for 370TCV
32556 Cam Guide for 370TCV
Item No. Description
32575 Carriage Slide Bar for 370TCV
32576 Slide Bar Cover for 370TCV
32577 Bottom Plate for 370TCV
32578 Top Plate for 370TCV
32579 Carriage Handle for 370TCV
32580 Flat Bar for 370TCV
32581 Bearing Support Bar for 370TCV
32582 Carriage Support for 370TCV
32583 Carriage Rail for 370TCV
32584 Bracket for 370TCV
32585 Plate Bracket for 370TCV
32586 Carriage Plate Rod for 370TCV
32587 Slide Bar Cap for 370TCV
32588 Rail Support for 370TCV
32589 Slide Bar Support for 370TCV
32590 Spacer Plate for 370TCV
13650
Position Item No. Description
1 32558 Cam Plate for 370TCV
2 32559 Set Screw 8x10 TC for 370TCV
3 32560 Bolt 5x20 for 370TCV
4 32561 Nut 5 for 370TCV
5 32562 Screw TPSV 5x10 for 370TCV
6 - 8, 21 32563 Screw TC 5x10 for 370TCV
9 32564 Screw TE 6x12 for 370TCV
10 32565 Tapping Screw 2.9x12 for 370TCV
11 32566 Washer 8 for 370TCV
12 32567 Copper Rivet for 370TCV
Position Item No. Description
1 32591 Slide Bar Spring for 370TCV
2 32592 Nut 6 for 370TCV
3 32593 Washer 6 for 370TCV
4 32594 Set Screw 6x30 for 370TCV
5 32595 Screw TE 8x40 for 370TCV
6 32596 Washer 8 for 370TCV
7 32597 Nut 8 for 370TCV
8 32598 Washer 8 for 370TCV
9 32599 Bushing for 370TCV
10 32600 Set Screw 6x12 for 370TCV
11 32601 Bearing 626 for 370TCV
12 32602 Bearing 608 for 370TCV
13 32603 Bearing Pin 8 for 370TCV
14 32604 Screw TPSV 5x10 for 370TCV
15 32605 Screw TE 8x20 for 370TCV
16 32606 Screw TE 8x25 for 370TCV
Position Item No.
13 32568
14 32569
15 32570
16 32571
17 32572
18 32573
19 32574
20 32557
22
23
Position Item No.
17 32607
18 32608
19 32609
20 32610
21 32611
22 32612
23 32613
24 32614
25 32615
26 32616
27 32617
28 32618
29 32619
30 32620
31
32
40
Stand
Description Position
Set Screw - Capped for 370TCV 24
Nut 8 for 370TCV 25
Set Screw 6x8 TP for 370TCV 26
Washer 5 for 370TCV 27
Screw TE 6x12 for 370TCV 28
Washer 6 for 370TCV 29
Screw TE 8x40 for 370TCV 30
Cam Assembly for 370TCV
Guide
Description Position
Set Screw 5x8 TC for 370TCV 33
Set Screw PVC for 370TCV 34
Rubber Washer 15 for 370TCV 35
Carriage Plate Spring for 370TCV 36
Washer 5 for 370TCV 37
Acorn Cap for 370TCV 38
Set Screw 5x20 TP for 370TCV 39
Set Screw PVC for 370TCV 40
Screw TE 8x20 for 370TCV 41
Screw TPSV 4x10 for 370TCV 42
Flat Latch for 370TCV 43
Threaded Stud 8 for 370TCV 44
Nut 6 for 370TCV 45
Screw TC 4x5 for 370TCV 46
