Omcan MS-IT-0300-V, MS-0330-V,MS-0350-V, MS-0370-V Instruction Manual page 39

Model MS-IT-0350-V
Item No. Description
32472 Capacitor for 350TCV
32473 Capacitor Bracket for 350TCV
32474 Washer 5 for 350TCV
32475 Screw 5x10 TC for 350TCV
32476 Switch - On / Off for 350TCV
32477 Motor for 350TCV
14859 Power Cord for 350TCV
Item No. Description
32490 Sharpener Support Bracket for 350TCV
32491 Screw TPSV 6x12 for 350TCV
32492 Shaft for Sharpener for 350TCV
32493 Set Screw 5x40 for 350TCV
32494 Set Screw 5x30 for 350TCV
32495 Nut 6 for 350TCV
32496 Sharpener Screw for 350TCV
32497 Ball Bearing for 350TCV
32498 Washer 6 for 350TCV
32499 Nut 6 for 350TCV
Item No. Description
32517 Screw TE 8x35 for 350TCV
32518 Washer 8 for 350TCV
32519 Carriage Plate Support V for 350TCV
32520 Carriage Plate Support H for 350TCV
32521 Nut for 350TCV
32522 Washer 6x18 for 350TCV
32523 Carriage Safety Guard for 350TCV
32524 Stud 6x50 for 350TCV
32525 Spacer for 350TCV
32526 Carriage Plate - Large for 350TCV
13649
Position Item No. Description
1 32479 Wing Nut for 350TCV
2 32480 Washer 6A Wide for 350TCV
3 32481 Motor Bracket for 350TCV
4 32482 Adjustment Rod for 350TCV
5 - 7 32483 Motor Support Shaft for 350TCV
9 - 11, 16 32484 Motor Hinge for 350TCV
11 32485 Set Screw 5x8 TC for 350TCV
Position Item No. Description
1 32500 Sharpener Push Button for 350TCV
2 32501 Spring for 350TCV
3 32502 Screw TC for 350TCV
4 32503 Washer 3 for 350TCV
5 32504 Sharpener Pin for 350TCV
6 32505 Sharpener Pin for 350TCV
7 32506 Sharpener Body for 350TCV
8 32507 Screw TC 4x20 for 350TCV
9 32508 Washer 4 for 350TCV
10 32509 Sharpener Tie Rod for 350TCV
Position Item No. Description
1 32527 Screw TE 8x20 for 350TCV
2 32528 Washer 8 for 350TCV
3 32529 Stud 5 MA for 350TCV
4 32530 Carriage Plate - Small for 350TCV
5 32531 Washer 6x18 for 350TCV
6 32532 Nut 6 for 350TCV
7 32533 Meat Grip Handle for 350TCV
8 32534 Aluminum Spacer for 350TCV
9 32535 Wavy Washer for 350TCV
10 32536 Stud 12 MA for 350TCV
Parts Breakdown
Electrical Components
Position Item No.
12 32486
13 32487
14 32488
15 32489
17 17855
18 17867
19
Sharpening Assembly
Position Item No.
11 32510
12 32511
13 32512
14 32513
15 32514
16 32515
17 32516
18 32738
19 64809
20
Food Tray Assembly
Position Item No.
11 32537
12 32538
13 32539
14 32540
15 32541
16 32542
17 32543
18 32544
19 32545
20 32546
39
Description Position
Screw TC 4x10 for 350TCV 20
Terminal Block for 350TCV 21
Tapping Screw for 350TCV 22
Stop Plate for 350TCV 23
Belt for 350TCV
Motor for 350TCV
Description Position
Screw TE 8x20 for 350TCV 21
Washer 8 for 350TCV 22
Sharpener Cover for 350TCV 23
Sharpener Cover Knob for 350TCV 24
Screw TC 6x12 for 350TCV 25
Set Screw 6x8 TC for 350TCV 26
Finishing Stone for 350TCV 27
Grinding Stone for 350TCV 28
Complete Sharpening Assembly for
350TCV
Description Position
Presser Plate for 350TCV 21
Set Screw 6x8 TC for 350TCV 22
End Block for 350TCV 23
Inside Block for 350TCV 24
Set Screw 6x8 TC for 350TCV 25
Rubber Washer for 350TCV 26
Spacer for 350TCV 27
Bracket for 350TCV 28
Stud PVC for 350TCV 29
Presser Rod for 350TCV 30
