Gear-Driven Slicer
Model MS-IT-0330-N
Item 39477
Instruction Manual
Revised - 06/26/2017
Toll Free: 1-800-465-0234
Fax: 905-607-0234
Email: service@omcan.com
www.omcan.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-IT-0330-N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omcan MS-IT-0330-N

Summary of Contents for Omcan MS-IT-0330-N

  • Page 1 Gear-Driven Slicer Model MS-IT-0330-N Item 39477 Instruction Manual Revised - 06/26/2017 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com...

  • Page 2: Table Of Contents

    Table of Contents Model MS-IT-0330-N Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 7 Operation ----------------------------------------------------------------------------------------- 7 - 8 Maintenance ----------------------------------------------------------------------------------- 8 - 11 Troubleshooting...

  • Page 3: General Information

    If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents.

  • Page 4: Safety And Warranty

    Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia.
  • Page 5 Do not remove the labels placed on the machine and replace them if damaged. 1 YEAR PARTS AND LABOUR WARRANTY Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule an Omcan authorized service technician to repair the equipment locally.

  • Page 6: Technical Specifications

    Technical Specifications Model MS-IT-0330-N Blade Size 13” / 330mm Power 0.6 HP / 0.45 kW Cheese Slicing Slicing Volume* 8 hours or more Slicing Capacity 10.2” x 6.7” / 259 x 170mm | 9.25” / 235mm(Dia.) Cut Thickness 0 - 0.55” / 0 - 14mm...

  • Page 7: Installation

    Installation 3. Press pushbutton carriage start. SLICER FUNCTIONING AND USE The following products can be sliced: sausages, ham, cheese, bread. If large quantities of bread or cheese are usually cut it is advisable to mount a teflon coating. WARNING The following cannot be sliced: •...

  • Page 8: Operation

    10 mm less than the nominal diameter. For the replacement, ask the assistant service closest to you. WARNING The replacement of the blade is dangerous operation. Should the sharpening quality be not satisfactory, replace the stones by contacting Omcan. SHARPENING OPERATION DANGER The sharpening operation must be performed during the manual functioning.

  • Page 9: Maintenance

    Maintenance 2. Make sure that the machine is off. 3. Rotate the slice thickness control to zero to make sure that the blade is covered by the slice thickness plate. IMPORTANT During the following operations the blade must always be covered by the removable protection. 4.
  • Page 10 Maintenance CHECK OF THE ELECTRIC CABLE It is recommended to check the wear of the electric cable at regular intervals. SPARE PARTS In the event that replacement parts need to be fitted, request only original spare parts. CLEANING The machine must be cleaned once a day or more frequently if necessary. Clean all the parts using a cloth sprinkled with water and washing up liquid (do not use strong detergents) and a brush.

  • Page 11: Troubleshooting

    Maintenance direction of the arrow. 6. Follow these instructions to clean the back side of the blade. 7. With a cloth dry both sides of the blade following this procedure. 8. Insert a damp cloth between the blade and the protection ring. Pull it outwards and rotate it to clean the internal side of the protection ring.

  • Page 12: Parts Breakdown

    Troubleshooting REFERENCE Item Number Model Number Description Manufacturer Model Number Meat Slicer Gear Driven Automatic 13” / 39477 MS-IT-0330-N 330mm Blade 0.6 HP / 450W 120V/60/1 CXMATIC33 NSF cETLus Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 13 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 14 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 15 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 16 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 17 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 18 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 19 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 20 Parts Breakdown Model MS-IT-0330-N 39477...
  • Page 21 Parts Breakdown Model MS-IT-0330-N 39477 Item No. Description Position Item No. Description Position Item No. Description Position Bearing 2Z-6003 17x35x10 for 36535 Assembly Sharpener for CXMATIC33 A1036 36563 Carriage Bushing for CXMATIC33 B6213 36629 C8006 CXMATIC33 Ring EL.Benzing 6 Stainless Steel for Bushing for Carriage Support lg.23mm for...
  • Page 22 Parts Breakdown Model MS-IT-0330-N 39477 Item No. Description Position Item No. Description Position Item No. Description Position Spring 10.5x1x19 Stainless Steel for 17345 Cam Bearing for CXMATIC33 E1458 36744 M7023 23649 Knife Shaft Model C for CXMATIC33 P3378 CXMATIC33 36680...
  • Page 23 Parts Breakdown Model MS-IT-0330-N 39477 Item No. Description Position Item No. Description Position Item No. Description Position 17458 Contact Washer for CXMATIC33 R6806 36960 Switch Bracket for CXMATIC33 S9113 19697 Screw M5x16 for CXMATIC33 V6211 36889 Washer 10.5x16x1 for CXMATIC33...
  • Page 24 Parts Breakdown Model MS-IT-0330-N 39477 Item No. Description Position Item No. Description Position Item No. Description Position Stainless Steel Screw M6x25 for Stainless Steel Screw TCEI U5931 37104 Threaded Stud for CXMATIC33 V8042 37114 V8130 77630 V634415 CXMATIC33 M4x12 for CXMATIC33...

  • Page 25: Electrical Schematics

    Electrical Schematics Model MS-IT-0330-N 39477 Position Description Position Description Position Description Printed Circuit Board Blade Stop Push Button LED Power Supply Power Cord Blade Start Push Button Blade Motor Carriage Stop Push Button Capacitor 20uF Resistance 50W Carriage Start Push Button...

  • Page 26: Notes

    Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________...

  • Page 27: Warranty Registration

    Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté...
  • Page 28 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
