Omcan MS-IT-0300-V, MS-0330-V,MS-0350-V, MS-0370-V Instruction Manual page 32

Parts Breakdown
Model MS-IT-0300-V
Item No. Description
15182 Blade Shield for 300TCV
31956 Blade for 300TCV
31957 Aluminum Plate for 300TCV
31958 Bottom Cover for 300TCV
31959 Foot for 300TCV
31960 Blade Shield Knob Screw for 300TCV
31961 Washer 4 for 300TCV
31962 Set Screw 5x8 TP for 300TCV
31963 Bearing and Shaft for 300TCV
Item No. Description
31981 Support for Pusher Arm for 300TCV
31982 Washer 8 for 300TCV
31983 Screw TE 8x20 for 300TCV
31984 Set Screw 5x20 for 300TCV
31985 Set Screw 5x16 for 300TCV
31986 Set Screw 6x8 TC for 300TCV
31987 Rod Brake for 300TCV
31988 Set Screw 6x19 for 300TCV
31989 Spring 3.5x19 for 300TCV
31990 Spring 13.5x10 for 300TCV
31991 Iron Plate for 300TCV
31992 Brake Stud for 300TCV
Item No. Description
32017 Nut 5 for 300TCV
32018 Washer 5 for 300TCV
32019 Set Screw 54x30 / 5x25 for 300TCV
32020 Ring for 300TCV
13647
Position Item No. Description
1 31964 Pulley for 300TCV
2 31965 Bearing Spacer for 300TCV
3 31966 Bearing 6004 2RS for 300TCV
4 31967 Clip for 300TCV
5 31968 Clip for 300TCV
6 31969 Set Screw for 300TCV
7 31970 Set Screw 6x8 TC for 300TCV
8 31971 Set Screw PVC for 300TCV
9 31972 Tie Rod for 300TCV
Position Item No. Description
1 31993 Spring 9x15 for 300TCV
2 31994 Stud Brake for 300TCV
3 31995 Presser Brake for 300TCV
4 31996 Hand Grip Safety Guard for 300TCV
5 17862 Meat Grip Handle for 300TCV
6 31998 Screw TPSV 4x10 for 300TCV
7 31999 Screw TPSV 45x12 for 300TCV
8 32000 Presser Handle Bracket for 300TCV
9 32001 Rod and Spring for 300TCV
10 32002 Screw Chrome for 300TCV
11 32003 Washer 8 for 300TCV
12 32004 Screw TPSV 4x10 for 300TCV
Position Item No. Description
1 32021 Safety Ring Extension for 300TCV
2 32022 Support Ring for 300TCV
3 32023 Support Ring for 300TCV
4 32024 Set Screw 6x12 for 300TCV
Position Item No.
10 31973
11 31974
12 31975
14 31976
15 31977
16 31978
17 31979
18 31980
19
Meat Tray Assembly
Position Item No.
13 32005
14 32006
15 32007
16 32008
17 32009
18 32010
19 32011
20 32012
21 32013
22 32014
23 32015
24 32016
Position Item No.
5 32025
6 32026
7 32027
8
32
Blade Assembly
Description Position
Tie Rod Spacer for 300TCV 20
Thumb Screw for 300TCV 21
Washer for 300TCV 22
Plate Stop for 300TCV 23
Support Rail for 300TCV 24
Washer 8 for 300TCV 25
Screw TE 8x20 for 300TCV 26
Tapping Screw for 300TCV 27
Description Position
Washer 4x25 for 300TCV 25
Bearing 608 ZZ for 300TCV 26
Bearing Spindle for 300TCV 27
Pusher Arm for 300TCV 28
PVC Washer 15x25 for 300TCV 29
Presser Spacer for 300TCV 30
Presser Plate for 300TCV 31
Set Screw 6x6 TC for 300TCV 32
Presser Shaft for 300TCV 33
Hex Pin 8x31 for 300TCV 34
Locking Nut for 300TCV 35
Complete Arm Assembly for 300TCV
Blade Guard
Description Position
Meat Deflector for 300TCV 9
Thumb Screw 5 MA for 300TCV 10
Acorn Cap for 300TCV 11
