Omcan MS-IT-0300-V, MS-0330-V,MS-0350-V, MS-0370-V Instruction Manual page 35

Model MS-IT-0330-V
Item No. Description
17857 Blade Shield for 330TCV
32178 Blade for 330TCV
32179 Aluminum Plate for 330TCV
32180 Bottom Cover for 330TCV
32181 Foot for 330TCV
32182 Blade Shield Knob Screw for 330TCV
32183 Washer 4 for 330TCV
32184 Set Screw 5x8 TP for 330TCV
32185 Bearing and Shaft for 330TCV
Item No. Description
32203 Support for Pusher Arm for 330TCV
32204 Washer 8 for 330TCV
32205 Screw TE 8x20 for 330TCV
32206 Set Screw 5x20 for 330TCV
32207 Set Screw 5x16 for 330TCV
32208 Set Screw 6x8 TC for 330TCV
32209 Rod Brake for 330TCV
32210 Set Screw 6x19 for 330TCV
32211 Spring 3.5x19 for 330TCV
32212 Spring 13.5x10 for 330TCV
32213 Iron Plate for 330TCV
32214 Brake Stud for 330TCV
Item No. Description
32239 Nut 5 for 330TCV
32240 Washer 5 for 330TCV
32241 Set Screw 54x30 / 5x25 for 330TCV
32242 Ring for 330TCV
13648
Position Item No. Description
1 32186 Pulley for 330TCV
2 32187 Bearing Spacer for 330TCV
3 32188 Bearing 6004 2RS for 330TCV
4 32189 Clip for 330TCV
5 32190 Clip for 330TCV
6 32191 Set Screw for 330TCV
7 32192 Set Screw 6x8 TC for 330TCV
8 32193 Set Screw PVC for 330TCV
9 32194 Tie Rod for 330TCV
Position Item No. Description
1 32215 Spring 9x15 for 330TCV
2 32216 Stud Brake for 330TCV
3 32217 Presser Brake for 330TCV
4 32218 Hand Grip Safety Guard for 330TCV
5 32219 Meat Grip Handle for 330TCV
6 32220 Screw TPSV 4x10 for 330TCV
7 32221 Screw TPSV 45x12 for 330TCV
8 32222 Presser Handle Bracket for 330TCV
9 32223 Rod and Spring for 330TCV
10 32224 Screw Chrome for 330TCV
11 32225 Washer 8 for 330TCV
12 32226 Screw TPSV 4x10 for 330TCV
Position Item No. Description
1 32243 Safety Ring Extension for 330TCV
2 32244 Support Ring for 330TCV
3 32245 Support Ring for 330TCV
4 32246 Set Screw 6x12 for 330TCV
Parts Breakdown
Position Item No.
10 32195
11 32196
12 32197
14 32198
15 32199
16 32200
17 32201
18 32202
19
Meat Tray Assembly
Position Item No.
13 32227
14 32228
15 32229
16 32230
17 32231
18 32232
19 32233
20 32234
21 32235
22 32236
23 32237
24 32238
Position Item No.
5 32247
6 32248
7 32249
8
35
Blade Assembly
Description Position
Tie Rod Spacer for 330TCV 20
Thumb Screw for 330TCV 21
Washer for 330TCV 22
Plate Stop for 330TCV 23
Support Rail for 330TCV 24
Washer 8 for 330TCV 25
Screw TE 8x20 for 330TCV 26
Tapping Screw for 330TCV 27
Description Position
Washer 4x25 for 330TCV 25
Bearing 608 ZZ for 330TCV 26
Bearing Spindle for 330TCV 27
Pusher Arm for 330TCV 28
PVC Washer 15x25 for 330TCV 29
Presser Spacer for 330TCV 30
Presser Plate for 330TCV 31
Set Screw 6x6 TC for 330TCV 32
Presser Shaft for 330TCV 33
Hex Pin 8x31 for 330TCV 34
Locking Nut for 330TCV 35
Complete Arm Assembly for 330TCV
Blade Guard
Description Position
Meat Deflector for 330TCV 9
Thumb Screw 5 MA for 330TCV 10
Acorn Cap for 330TCV 11
