1. General Information

These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the PIR sensor
is switched off and the circuit supply fuses are removed or the circuit breaker
turned off.
• It is recommended that a qualified electrician is consulted or used for the
installation of this PIR sensor and install in accordance with the current
IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this PIR sensor is fitted
does not exceed the rating of the circuit cable, fuse or circuit breaker.

3. Technical Specifications

Power Box
1
• 230V AC 50 Hz
• This Power Box is of Class ll Construction and must not be earthed
• Maximum Switching Load;
• Mounting Centres:
• Manual Override Mode:
• IP20 Rated suitable for restricted internal applications
• CE Compliant
• Dimensions:
• The power box will fit through a 40mm diameter hole
2300W Halogen
500W Low loss balance fluorescent
250W Electronic balance fluorescent,
CFL and LED Lighting
165mm
Double pulse within 2 seconds to enter
6 hours ON time
H= 35mm, W= 175mm, D= 35mm
