1. General Information

These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the time
switch is switched off and the circuit supply fuses are removed or the
circuit breaker turned off.
• It is recommended that a qualified electrician is consulted or used
for the installation of this time switch and install in accordance
with the current IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this
time switch is fitted does not exceed the rating of the circuit cable,
fuse or circuit breaker.

3. Technical Specifications

• 230V AC 50 Hz
1 • This time switch is of Class l Construction and must be earthed
• Switch Rating:
• Switch Type:
• 24 hour Programme:
• Boost Times:
• Economy Output Light:
• Battery Backup:
• IP30 Rated suitable for restricted internal applications
• CE Compliant
• Dimensions (H x W x D):
13A Resistive (3kW) Immersion Heaters
Micro-disconnection ON control.
Disconnection to immersion heater(s)
via double pole rocker switch
10 selectable pre-set tariff
programmes (0 – 9)
30, 60, 120 minutes
Blue LED
2 year reserve, factory fitted
rechargeable non-replaceable
111.5 x 170 x 60mm
