1. General Information

These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the PIR sensor
is switched off and the circuit supply fuses are removed or the circuit breaker
turned off.
• It is recommended that a qualified electrician is consulted or used for
the installation of this PIR sensor and install in accordance with the
current IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this PIR sensor
is fitted does not exceed the rating of the circuit cable, fuse or circuit breaker.

3. Technical Specifications

• 230V AC 50 Hz
1
• This PIR is of Class ll Construction and must not be earthed
• Motion Detection Range:
• Presence Detection Range:
• Detection Angle:
• Maximum Switching Load:
• Time ON Adjustment:
• Dusk Level Adjustment:
• Minimum depth of Back Box: 16mm
• IP55 Rated suitable for restricted internal applications
• CE Compliant
• EC Directives:
Up to 10 metres diameter (4.5m Radius)
at a mounting height of 3 metres
Up to 3 metres diameter (1.5m Radius)
at mounting height of 3 metres
360°
1500W Halogen/Fluorescent Lighting
420W LED Lighting
420W Discharge Lighting (SON, HQI)
250W Fan Load
1 minute to 30 minutes
Day and Night or Night time only operation
Conforms to latest directives
