2 Hardware Installation

H
2
ARDWARE
The MobileView digital video recording system supports up to eight cameras, a DVR, a keypad interface,
single-channel audio, and an optional impact sensor, panic button, and microphone. Systems using the
transmission option (DVRT) also include a cellular modem and antenna.
Note: Most MobileView products are not supplied with mounting hardware. Exceptions are noted in the appropriate sections of the
manual.
2.1 T N
OOLS ECESSARY FOR
! MobileView Test Kit
! Laptop / viewing station
! Electrical volt meter
! BNC crimper
! Molex pin crimper
! Riv-nut gun
! Socket set up to 5/8 in.
! Wrenches up to 5/8 in.
! Phillips and flathead screwdrivers
! Solder gun with solder
! Wire strippers
! Drill
! Drill bits up to 5/8 in.
! Hole saws up to 1 1/8 in.
8
I
NSTALLATION
I
NSTALLATION
MobileView User Manual
! Locktite (blue)
! Torx bit secured #10
! Wire snake
! Extension cords
! 8-in. tie wraps
! Electrical tape
! Heat shrink
! Spare BNCs
! Spare Molex pins
! Electrical connections (ends, lugs, etc.)
! Relays, 12 and 24 VDC
! In-line fuses and 5-amp fuses
! Spare J9, J11, and J12 terminal blocks
! General tools
