5) Press the key. The "Subnet Mask" display appears.
6) Enter the following: 255.255.000.000
5.1.4 S V
YSTEM ARIABLE
1) If you want to set up system variables, use
the keys at the Setup System Variables menu
(Figure 70) to select "yes," and press the
key to advance to the System Capture Rate menu
(Figure 71). To skip system variables setup,
press the key while "no" is selected.
2) Use the keys to select the fields per second (fps)
rate.
If you are programming a MobileView II system, you can
select between 0.25 fps (one image
every 4 seconds) and 8 fps (eight images
per second).
If you are programming a MobileView III system, the
capture rate capabilities are tripled. However,
to ensure the keypad's backward compatibility,
the fps rates on the System Capture Rate
menu (Figure 71) are still listed at between
0.25 and 8 fps. See Table 1 to set the capture
rate for a MobileView III system.
1036564B / October 2002
S M
ETUP ENUS
5 DVR Configuration
CENTRAL IP ADDRESS:
___.___.___.___
SUBNET MASK:
255.255.000.000
Figure 69. Setup Transmission Menu (continued)
SETUP SYSTEM VARIABLES?
YES
Figure 70. Setup System Variables menu
SYSTEM CAPTURE RATE
4 FPS
Figure 71. System Capture Rate menu
Table 1. MobileView III fps conversions
Capture Rate listed Target Capture Rate
on System Capture for MobileView III
Rate menu system
8 fps
7 fps
6 fps
5 fps
4 fps
3 fps
2 fps
1 fps
0.75 fps
0.5 fps
0.25 fps
NEXT
NEXT
NEXT
NEXT
24 fps
21 fps
18 fps
15 fps
12 fps
9 fps
6 fps
3 fps
2 fps
2 fps
1 fps
