MobileView User Manual
A
D. DVR C
PPENDIX
Property Name:
1. Inputs 1 – 6
1. ____________
2. ____________
3. ____________
4. ____________
5. ____________
6. ____________
2. Camera(s) 1 – 8
Camera 1
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 1 Trigger Capture Rate: Fast – Slow – Normal
Camera 1 Trigger Picture Quality: High – Medium – Low
Camera 2
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 2 Trigger Capture Rate: Fast – Slow – Normal
Camera 2 Trigger Picture Quality: High – Medium – Low
Camera 3
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 3 Trigger Capture Rate: Fast – Slow – Normal
Camera 3 Trigger Picture Quality: High – Medium – Low
Camera 4
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 4 Trigger Capture Rate: Fast – Slow – Normal
Camera 4 Trigger Picture Quality: High – Medium – Low
1036564B / October 2002
W
ONFIGURATION
Outputs 1 and 2
1. ____________
2. ____________
Camera 5
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 5 Trigger Capture Rate: Fast – Slow – Normal
Camera 5 Trigger Picture Quality: High – Medium – Low
Camera 6
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 6 Trigger Capture Rate: Fast – Slow – Normal
Camera 6 Trigger Picture Quality: High – Medium – Low
Camera 7
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 7 Trigger Capture Rate: Fast – Slow – Normal
Camera 7 Trigger Picture Quality: High – Medium – Low
Camera 8
Color – B&W – Disable
Camera Name <________________>
Capture Rate: Fast – Slow – Normal
Picture Quality: High – Medium – Low
Camera 8 Trigger Capture Rate: Fast – Slow – Normal
Camera 8 Trigger Picture Quality: High – Medium – Low
Appendix D. DVR Configuration Worksheet
ORKSHEET
47
