3.2.2 C K
AMERA AND
Note: If you are installing the keypad more than 100 feet (30 m) from the DVR, set the S1 switch (
position. If you are installing eight cameras (system maximum), set the S2 switch (
CAUTION
Do not confuse the J9 terminal block with the J11 terminal block. The J9 is above the J11 and is for
camera and keypad connections; the J11 is for input/output wiring.
3.2.2.1 J9 T B
ERMINAL LOCK
The J9 terminal block provides power to the vehicle's cameras and the keypad.
1) Remove the J9 terminal block (
and pulling it out of its socket.
2) Make connections as shown in Figure 26. To make connections, strip each wire 3/8 inch (9.5 mm),
insert it into the appropriate slot, and tighten the terminal screw.
3) Reinstall the J9 terminal block.
Power 1
Power 2
Power 3
Power 4
Figure 26. J9 terminal block connections
3.2.2.2 BNC C
ONNECTIONS
Connect each camera's video output
cable to its corresponding BNC connector
on the back box. See Figure 27.
Camera 1 connects to J1, camera 2 to J2, etc.
Note: Camera numbers will not always correspond
one to one with the BNC connectors. Be sure to
connect the appropriate BNC port, according to
specific system design.
20
W
EYPAD IRING
C
ONNECTIONS
in Figure 24) from the back box by loosening its mounting screws
Power 5
Power 6
Power 7
Power 8
in Figure 24) to the down position.
Keypad power
Keypad RS485 communication
Figure 27. BNC connectors
MobileView User Manual
in Figure 24) to the down
1036564B / October 2002
