3 DVR Installation and Wiring
3.3
R
EASSEMBLING THE
1)
Make sure that all wire connections are secure and that all terminal boards are securely fastened to
the back box; 1.25-inch (32 mm) connectors can be used.
2)
Reconnect the splashguard to the back box following the contour of the wiring. See Figure 25
3)
Reconnect the back box to the DVR outer housing (see Figure 22), or go to
section 4 Testing Connections and reinstall the connection box when testing is complete.
