Visual Productions CUECORE2 Manual page 92

Feature Function
Program Stop
Program Record
Program Erase
Intensity Map Clear
Intensity Map Capture DMX
Intensity Map Capture Art-Net
Intensity Map Capture sACN
B.4 UDP
Send an UDP message via the network. Specify the recipient in Parameter 2.
For example "192.168.1.11:7000".
Feature Function
Send Float Set
Send Float Control
Send Unsigned Set
Send Unsigned Control
Send Bool Set
Send Bool Control
Send String Set
Send String Control
Wake On Lan Set
Please note that string in parameter 1 has a maximum length of 31 charac-
ters.
When using the Wake On Lan feature parameter 1 should contain the MAC
Address of system's NIC (Network Interface Controller) you wish to wake up.
The recommended value for parameter 2 is 255.255.255.255:7. This broad-
casts the message to the whole network at port 7 which is most commonly used
for Wake On Lan.
B.5 OSC
Send an OSC message via the network. The OSC recipients are specified in the
Settings page.
Parameter 1
-
Track Index
Track Index
-
-
-
-
Parameter 1
floating point number
-
positive number
-
true or false
-
text string
-
MAC Address
92
Parameter 2
-
-
-
-
-
-
-
Parameter 2
IP address & port
IP address & port
IP address & port
IP address & port
IP address & port
IP address & port
IP address & port
IP address & port
IP address & port
