A.2 MIDI
Trigger Type Trigger Value
Message MIDI address
Message MIDI address
Message MIDI address
Receiving -
MIDI address can be any note-on, note-off or control-change.
A.3 DMX Input
Trigger Type Trigger Value
Channel DMX Address
Channel DMX Address
Channel DMX Address
UniverseA -
UniverseB -
Receiving -
Receiving -
Receiving -
Flank Description
Change Receive a message that matches the address
Down Receive a message that matches the address and
the value non-zero
Up Receive a message that matches the address and
the value is zero
- Receive any message
Flank Description
Change Channel changes
Non-zero Channel becomes non-zero
Zero Channel becomes zero
- A DMX level change in the first universe
- A DMX level change in the second universe
Change Start receiving or loose DMX signal
Stop Lost DMX signal
Start Start receiving DMX signal
